5MP Smart Dual Illumination Bullet Network Camera

SN-IPR5150DUAS-B
  • 1/3” progressive scan CMOS

  • 4 mm fixed lens

  • Max resolution 5MP (2560×1920) @20fps

  • Support intrusion and line crossing based on human detection

  • DWDR, 3D DNR, HLC, BLC, Defog

  • Built-in IR LED and warm lights, IR illumination distance up to 30m, white light distance up to 30m

  • Built-in microphone

  • 12V DC/PoE power supply

  • IP66


Specification

Camera

Image Sensor

1/3” Progressive Scan CMOS

Electronic Shutter

Auto/Manual, 1/5 ~ 1/20,000s

Min. illumination

Color: 0.1 Lux @ (F1.6,AGC ON) ,

B/W: 0 Lux @ (IR LED ON)

S/N Ratio

55 dB

Day & Night

IR cut filter

Wide Dynamic Range

DWDR

Illumination Distance

IR distance up to 30 m (98.4 ft),

White light distance up to 30 m (98.4 ft)

Illumination On/Off Control

Auto/Manual

Lens

Lens Type

Fixed focal

Iris

Fixed Iris

Focal Length

4 mm

F Number

F1.6

Angle of View

H: 80.6°, V: 41.5°

Video

Max. Resolution

2560(H)×1920(V)

Streaming Capability

2 Streams

Stream/Frame Rate

Main Stream: 2560×1920, 2560×1440, 2304×1296, 1920×1080, 1280×720, 704×576 @ 20fps

Sub Stream: 640×360 @ 20fps

Bit Rate Control

CBR/VBR

Bit Rate

Main Stream: 512kbps ~ 6144kbps

Sub Stream: 128kbps ~ 1536kbps

Video

Image Adjustment

Brightness, Sharpness, Contrast, Saturation

White Balance

Auto/Manual

Mirror

Support

Exposure Mode

Auto/Manual

Day/Night Setting

Auto, Day, Timing

Noise Reduction

2D/3D NR

Image Enhancement

WDR, HLC, BLC, Defog

Privacy Masking

Support

Alarm Event

Motion Detection

Support

Smart Event

Support intrusion and line crossing based on human detection

Network

Protocols

IPv4, RTSP/RTP/RTCP, TCP/UDP,DHCP, DNS, DDNS, UPNP, ICMP, IGMP, NTP, SMTP, 802.1x, SNMP, HTTP/HTTPS, PPPOE

Interoperability

ONVIF, SDK

Max. User Access

4 Users

Web Viewer

<IE11, Chrome, Firefox, Microsoft Edge

Management Software

SunView

Interface

Network Interface

1 Ethernet (10/100 Base-T) RJ-45 Connector

Built-in Microphone

Yes

Built-in Speaker

Yes

SD Card Slot

Built-in, up to 256GB

Reset Button

Support

Electrical

Power Supply

DC12V(-15%~+25%)/POE (IEEE 802.3af)

Power Consumption

Max 8W

Operating Temperature

-25°C ~ 55°C (-13°F ~ 131°F )

Operating Humidity

Less than 90% RH

Ingress Protection

IP66

Certifications

CE/FCC

Casing

Metal + Plastic

Dimensions

314 × 118 × 169 mm (12.36 × 4.65 × 6.65 inch)

Net Weight

0.83 Kg (1.83 lb)



Dimensions Of 5MP SN-IPR5150DUAS-B

Dimensions Of 5MP SN-IPR5150DUAS-B
