Video Input | |
IP Camera Input | 4 Channel |
Incoming Bandwidth | 40 Mbps |
Outgoing Bandwidth | 40 Mbps |
Video Output | |
HDMI Output | 3840 × 2160, 1920 × 1080, 1280 × 1024, 1024 × 768 |
VGA Output | 1920 × 1080, 1280 × 1024, 1024 × 768 |
Decoding Capacity | 1ch 8MP, 4ch 1080P |
Dual Stream | Support |
Multi-screen Display | 1/4 |
Recoding | |
Resolution | 8MP, 6MP, 5MP, 4MP, 3MP, 1080P, 720P, D1 etc. |
Recording Mode | Manual, Schedule (Regular, Continuous), Event |
Trigger Events | Motion Detection, Video Loss, IVS |
Playback and Backup | |
Sync Playback | 4/1 |
Search Mode | Time /Date, Alarm, Picture grid, Event |
Backup Mode | USB Device, Network |
Alarm | |
General Alarm | Motion Detection, Video Loss |
Intelligent Analysis (By Camera) | Smoking Detection, Smoke and Fire Detection, Fire Spot Detection, Intrusion, Single Line Crossing, Double Line Crossing, Loitering, Wrong-way, Illegal Parking, People Counting, Smart motion detection, Enter Area, Leave Area, etc. |
Abnormal Alarm | Disk Alarm, IP Address Conflict, Network Disconnect |
Network | |
Network Function | HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, UDP, RTSP, SMTP, NTP, DNS, DHCP, P2P, IP Filter, DDNS, 802.1X, SNMP, 3G/4G, PPPoE |
Remote Users | 8 users |
P2P | Support |
Interoperability | ONVIF, SDK, CGI |
Storage | |
ANR | Support |
Interface | |
HDD Interface | 1 SATA interfaces, up to 8TB capacity for each disk |
Network Interface | 1 × RJ-45, 10/100 Mbps self-adaptive Ethernet port |
PoE Interface | 4 ports, 10/100Mbps, 802.3af, max 24W |
HDMI | 1 |
VGA | 1 |
Audio In/Out | 1ch audio output |
USB Interface | Front panel: 2 × USB 2.0, Rear panel: 1 × USB 2.0 |
General | |
Power Supply | 48VDC/1.25A |
Power Consumption | < 15 W (without HDD) |
Operating Conditions | -10 °C to 50 °C (14 °F to 122 °F) |
Storage Conditions | Less than 90% RH |
Certifications | CE/FCC |
Dimensions | 255 × 235.0 × 45.3 mm (10.04 × 9.25 × 1.78 inch) |
Net Weight | 0.9 kg (1.98 lb) without HDD |
