Video Input | |
IP Camera Input | 4 Channel |
Incoming Bandwidth | 40 Mbps |
Outgoing Bandwidth | 40 Mbps |
Video Output | |
HDMI Output | 1920 × 1080, 1280 × 1024, 1024 × 768 |
VGA Output | 1920 × 1080, 1280 × 1024, 1024 × 768 |
Decoding Capacity | 1ch 6MP, 4ch 1080P@30fps |
Dual Stream | Support |
Multi-screen Display | 1/4 |
Recoding | |
Resolution | 6MP, 5MP, 4MP, 3MP, 1080P, 720P, D1 etc. |
Recording Mode | Manual, Schedule (Regular, Continuous), Event |
Trigger Events | Motion Detection, Video Loss, IVS |
Playback and Backup | |
Sync Playback | 4-ch |
Search Mode | Time /Date, Alarm, Picture grid, Event |
Backup Mode | USB Device, Network |
Network | |
Network Function | HTTP, HTTPS, TCP/IP, IPv4, IPv6, UPnP, UDP, RTSP, SMTP, NTP, DNS, DHCP, P2P, IP Filter, DDNS, 802.1X, SNMP, PPPoE |
Remote Users | 8 users |
Smart Phone | iOS, Android |
Interoperability | ONVIF, SDK |
Storage | |
ANR | Support |
Interface | |
HDD Interface | 1 SATA interface, up to 8TB capacity for each disk |
Network Interface | 1 RJ-45 (10/100 Mbps) self-adaptive Ethernet port |
USB | Rear panel: 2 × USB 2.0 |
HDMI | 1 |
VGA | 1 |
General | |
Power Supply | DC12V/2A |
Power Consumption | < 5 W (without HDD) |
Operating Conditions | -10 °C to 50 °C (14 °F to 122 °F) |
Storage Conditions | Less than 90% RH |
Certifications | CE/FCC |
Dimensions | 254.5 × 224.4 × 43.9 mm (10.02 × 8.83 × 1.73 inch) |
Net Weight | 0.62 kg without HDD |
