Camera | ||||
Image Sensor | 4 × 1/2.8” Progressive Scan CMOS | |||
Max Resolution | 8MP, 3840(H) × 2160(V) | |||
Shutter Speed | 1/5 to 1/100,000s | |||
Min Illumination | Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0.001 Lux @ (F1.6, AGC ON), 0 Lux with IR on | |||
Day & Night | Auto (ICR) | |||
Angle Adjustment | Pan: -180˚ to 180˚, Tilt: 0˚ to 130˚, Rotation: 0˚ to 355˚ | |||
Lens | ||||
Lens Type | Varifocal lens, Motorized focal | |||
Focal Length | 2.7 to 13.5 mm | |||
Max. Aperture | F1.6 | |||
Field of View (FOV) | H: 108.0° to 31.4°, V: 56.1° to 17.6° | |||
Iris | Auto Iris | |||
DORI Distance | ||||
Detect | 95 to 290 m (311.7 to 951.4 ft) | |||
Observe | 38 to 116 m (124.7 to 380.6 ft) | |||
Recognize | 19 to 58 m (62.3 to 190.3 ft) | |||
Identify | 9.5 to 29 m (31.2 to 95.1 ft) | |||
Illuminator | ||||
Type | IR | |||
IR wavelength | 850 nm | |||
Distance | Up to 40 m (131.2 ft) | |||
Control | Auto/ Manual | |||
Intelligent Analytics | ||||
AI Multi-Target | - Supports face, human, and vehicle detection & capture - Supports human and vehicle attribute detection - Supports multiple frame modes: Full Frame, Four-Corner Frame, Mosaic | |||
Attribute Extraction | Human Attributes: Gender, age, glasses, hat, bag, upper clothing color & style, lower clothing color & style, reflective vest Vehicle Attributes: Type, color, brand, orientation | |||
Intelligent Analysis | Intrusion, smart motion detection, single line crossing, double line crossing, loitering, wrong-way detection, area people limit, perimeter detection, illegal parking, running detection, fall detection, fight detection, enter area, and leave area - Supports accurate target classification (human/vehicle) | |||
People Counting | Supported | |||
Video & Audio | ||||
Number of Streams | 3 Streams | |||
Resolution | Stream1: 3840 × 2160, 2592 × 1944, 2592 × 1520, 2560 × 1440, 2304 × 1296, 1920 × 1080, 1280 × 720 Stream2: D1, VGA, CIF Stream3: VGA, CIF, QVGA | |||
Frame Rate | Up to 25/30fps | |||
Bit Rate Control | CBR/VBR | |||
Bit Rate | Stream1: 200 Kbps to 16 Mbps Stream2: 100 Kbps to 6 Mbps Stream3: 100 Kbps to 3 Mbps | |||
Smart Encoding | Supported | |||
Region of Interest (ROI) | Off / On (8 Zone, Rectangle) | |||
Audio Compression | G.711 A-law, G.711 μ-law, RAW_PCM | |||
Audio Bit Rate | 64 Kbps (G.711), 128 Kbps (RAW_PCM) | |||
Image | ||||
Image Adjustment | Brightness, Sharpness, Contrast, Saturation adjustable | |||
Scene Mode | Indoor, Outdoor, Mirror, Corridor mode | |||
Exposure Mode | Auto, Manual, Shutter priority | |||
White Balance | Auto, Tungsten, Fluorescent, Daylight, Shadow, Manual | |||
Day/Night Setting | Auto, Day, Night, Timer | |||
Noise Reduction | 2D/3D DNR | |||
Image Enhancement | WDR, HLC, BLC, Defog | |||
Wide Dynamic Range | True WDR (120dB) | |||
Privacy Masking | Up to 4 × 4 areas | |||
Event | ||||
Alarm Triggers | IVS, Motion detection, Alarm input, Network alarm, Disk alarm, Day/Night switch alarm, Abnormal sound detection | |||
Event Actions | Alarm record, Alarm output, FTP upload, SMTP upload, Snapshot, Audible alarm output | |||
Network | ||||
Protocols | IPv4/IPv6, HTTP/HTTPS, DNS, DDNS, DHCP, PPPoE, RTSP/ RTCP/RTP, TCP/UDP, NTP, ARP, UPnP, FTP, SMTP, QoS, ICMP, IGMP, SMTP, 802.1x, SNMP, Multicast | |||
Application Programming Interface | ONVIF (Profile S/T/G/M), SDK, CGI | |||
Max Concurrent Streams | 10 channels | |||
User/Host Level | 32+ users, 3 levels: Administrator, Operator, Media user | |||
Web Viewer | <IE11, Chrome, Firefox, Microsoft Edge | |||
Security | ||||
OS / Firmware Protect | Encrypted firmware, Secure boot, Signed firmware | |||
User Authentication | Digest authentication, Prevent brute-force attack | |||
Network Authentication | IEEE 802.1X (EAP-TLS) | |||
Secure Communication | HTTPS, WSS(WebSocket Secure), SRTP | |||
Access Control | IP-based access control, Auto logout | |||
Data Protect | Encryption credentials | |||
Audit | Access / System / Event Log management | |||
Secure Storage | SDcard partition encrypt(AES-256), Secure element | |||
Supply Chain Security | SBOM | |||
Interface | ||||
Network Interface | 1 × Ethernet (10/100 Base-T), RJ-45 connector | |||
Built-in Microphone | Supported | |||
Audio Interface | 1ch Input, 1ch Output | |||
Alarm Interface | 4ch Input, 2ch Output | |||
RS-485 | 1 RS-485 | |||
CVBS Output | Supported | |||
SD Card Slot | Built-in microSD card slot, up to 1 TB | |||
Reset Button | Supported | |||
General | ||||
Language | English, Chinese, Traditional Chinese, Polish, Italian, Portuguese, Spanish, Russian, French, Czech, Hungarian, Japanese, Korean. Default: English | |||
Power Supply | 12 VDC (-15% to +25%) / PoE+ (802.3at) | |||
Power Consumption | Typical: 10.8 W (12 VDC) / approx. 13.5 W (PoE) Max (IR on): 20.2 W (12 VDC) / approx. 25.3 W (PoE) | |||
Operating Temperature | -40°C to 60°C (-40°F to 140°F ) | |||
Operating Humidity | Less than 95% RH | |||
Ingress Protection | IP67, IK10 | |||
Certifications | CE-EMC - EN 55032, EN IEC 61000-6-4, EN IEC 61000-3-2, EN 61000-3-3, EN 55035, EN 50130-4 FCC 47 CFR Part 15 Subpart B | |||
Material | Aluminum alloy body, bubble: plastic | |||
Dimensions | Φ282 × 206.3 mm (φ11.1 × 8.12 inch) , (Bracket not included) | |||
Net Weight | Approx. 4 kg (8.82 lb), (Bracket not included) | |||
