Video and Audio | |
Analog Video Input | 8-ch BNC interface, Supports coaxial control |
AHD Input | 1080P, 720P |
TVI Input | 1080P, 720P |
CVI Input | 1080P, 720P |
CVBS Input | PAL/NTSC |
IP Video Input | 2-ch (only IP up to 10-ch), each channel up to 1080P |
HDMI Output | 1920 × 1080, 1280 × 1024, 1024 × 768 |
VGA Output | 1920 × 1080, 1280 × 1024, 1024 × 768 |
Audio Input | 1-ch RCA, 8-ch via coaxial cable |
Audio Output | 1-ch RCA |
Two-way Audio | Supported via RCA and Network (Half-Duplex Intercom) |
Recording | |
Encoding Resolution | 1080P, 720P, 960H, D1, CIF |
Frame Rate | 1080P @ 7 fps |
Video Bit Rate | Main stream: 16 Kbps to 2048 Kbps, Sub stream: 16 Kbps to 1024 Kbps |
Dual Stream | Support |
Audio Compression | G.711 |
Playback and Backup | |
Recording Mode | Manual, Alarm, Motion detection, Timing |
Recording Playback | 16/9/4/1 |
Search Mode | Time /Date, Alarm, Picture grid, Event |
Backup Mode | USB Device, Network |
Network | |
Protocols | HTTP, HTTPS, TCP/IP, IPv4, IPv6, UPnP, UDP, RTSP, SMTP, NTP, DNS, DHCP, P2P, IP Filter, DDNS, 802.1X, SNMP |
Remote Users | 4 |
Smart Phone | iPhone, iPad, Android |
Interoperability | ONVIF, SDK, CGI |
Storage | |
HDD | 1 SATA interfaces |
Capacity | Up to 4TB capacity for each disk |
Interface | |
Network Interface | 1 RJ45 10M/100M self-adaptive Ethernet Interface |
Alarm In/Out | N/A |
USB Interface | 3 ports (1 front USB 2.0 port, 2 rear USB 2.0 port) |
General | |
Power Supply | 12 VDC/2A |
Power Consumption | Max 15W (without HDD) |
Working Temperature | -10 °C to 50 °C (14 °F to 122 °F) |
Working Humidity | Less than 90% RH |
Certifications | CE-EMC - EN 55032, EN IEC 61000-3-2, EN 61000-3-3, EN 55035 CE-LVD - EN IEC 62368-1 FCC 47 CFR Part 15 Subpart B |
Dimensions (W×D×H) | 255 × 225 × 45 mm (10.04 × 8.86 × 1.77 inch) |
Net Weight | 0.7 kg (1.54 lb) without HDD |
