Video and Audio | |
Analog Video Input | 8-ch BNC interface, Supports coaxial control |
AHD Input | 8MP, 5MP, 4MP, 3MP, 1080P, 720P |
TVI Input | 8MP, 5MP, 4MP, 3MP, 1080P, 720P |
CVI Input | 8MP, 5MP, 4MP, 3MP, 1080P, 720P |
CVBS Input | PAL/NTSC |
IP Video Input | 4-ch (only IP up to 12ch), each channel up to 5MP |
HDMI Output | 3840 × 2160, 1920 × 1080, 1280 × 1024,1024 × 768 |
VGA Output | 1920 × 1080, 1280 × 1024,1024 × 768 |
CVBS Output | N/A |
Audio Input | 8-ch, 8-ch via coaxial cable |
Audio Output | 1-ch |
Two-way Audio | Supported via RCA and Network (Half-Duplex Intercom) |
Perimeter Protection | |
Intrusion Detection | 8-ch, Support accurate detection of human and vehicle |
Recording | |
Resolution | 8MP, 5MP, 4MP, 3MP, 1080P, 720P, D1 etc. |
Frame Rate | |
Video Bit Rate | Main stream: 128 Kbps to 6144 Kbps, Sub stream: 16 Kbps to 1024 Kbps |
Dual Stream | Support |
Audio Compression | G.711 |
Playback and Backup | |
Recording Mode | Manual, Alarm, Motion detection, Timing |
Recording Playback | 8/4/1 |
Search Mode | Time /Date, Alarm, Picture grid, Event |
Backup Mode | USB Device, Network |
Network | |
Network Function | HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, UDP, RTSP, SMTP, NTP, DNS, DHCP, P2P, IP Filter, DDNS, 802.1X, SNMP |
Remote Users | 4 users |
Smart Phone | iPhone, iPad, Android |
Interoperability | ONVIF, SDK, CGI |
Storage | |
HDD | 2 SATA interface |
Capacity | Up to 8TB for each disk |
Disk Group | Support |
Interface | |
Network Interface | 1 RJ-45 (10/100 Mbps) self-adaptive Ethernet port |
USB | Front panel: 1 × USB 2.0, Rear panel: 2 × USB 2.0 |
Alarm In/Out | 4/1 |
RS-485 | 1 port, for PTZ control |
General | |
Power Supply | 12 VDC/4A |
Power Consumption | < 15 W (without HDD) |
Operating Conditions | -10 °C to 50 °C (14 °F to 122 °F) |
Storage Conditions | Less than 90% RH |
Certifications | CE-EMC - EN 55032, EN IEC 61000-3-2, EN 61000-3-3, EN 55035 CE-LVD - EN IEC 62368-1 FCC 47 CFR Part 15 Subpart B |
Dimensions (W × D × H) | 350 × 305 × 50 mm (13.78 × 12.01 × 1.97 inch) |
Net Weight | 1.76 kg (3.88 lb) without HDD |
