Parameters |
Application Model | SN-IPCXXXXHAN |
Color | White |
Fan | Support |
Illumination Type | IR |
Wavelength | 850 nm |
Illumination Distance | ≥ 80 m |
Illumination Setting (Automatic Control) | 1 to 3 Lux on, 2 to 6 Lux off |
IR Control | Photosensitive automatic control (default) / Camera control Two optional options |
Power Supply | DC12V or PoE+ (802.3at) optional |
Power | Max. 30W (IR + fan on) |
Working Temperature | -20°C to 60°C (-4°F to 140°F) |
Operating Humidity | 0% to 90% RH |
Ingress Protection | IP66 |
Window Size | 110 × 90 mm (max. support for lenses with an outer diameter of less than 63mm) |
Internal Installation Space (L × W × H) | 275 × 110 × 90 mm (10.83 × 4.33 × 3.54 inch) |
Product Dimensions (L × W × H) | 471.1 × 172.3 × 125.2 mm (18.55 × 6.78 × 4.93 inch) |
Product Weight | 2.4 kg (5.29 lb) |
