Radar Characteristics | |
Radar Sensor | FMCW |
Radar Output Data | Distance, direction, angle |
Transmit Frequency | 61.2 to 61.5 GHz |
Refresh Rate | 10 Hz |
EIRP | 22 dBm |
Power Consumption | 3 W |
Detection Performance | |
Target Identification | Small animals, people, vehicles |
Recognition Pattern | Radar triggers an alarm, linkage video review |
Detection Range (Pedestrian) | 1 ~ 60 m |
Detection Range (vehicle) | 1 ~ 60 m |
Detection Accuracy | ±0.5 m |
Detection Resolution | 0.67 m |
Speed Range | 0.5 m/s ~ 30 m/s |
Speed Accuracy | 0.03 m/s |
Speed Resolution | 0.06 m/s |
Angle Accuracy | ±1° |
FOV | Azimuth: 120°, Elevation: 22° |
Hardware Characteristics | |
Communication Protocol | UDP, TCP, RS485 |
Network Interface | 1 RJ45 10M/100M (PoE) |
Alarm Interface | 2ch output, 1ch intput |
RS485 | Support |
Relay | 2ch output |
Physical Characteristics | |
Power Supply | 12 VDC / PoE (IEEE802.3af) |
Working Temperature | -40 ~ 75°C |
Storage Temperature | -40 ~ 85°C |
Dimension | 149.4 × 125.5 × 45.2 mm |
Protection Grade | IP66 |
