Image Sensor

Dual 1/2.8” Progressive Scan CMOS

Max. Resolution

8MP, 4224(H) × 1848(V)

Electronic Shutter

Auto/Manual, 1/5 to 1/100,000s

Min. illumination

Color: 0.01 Lux @ (F1.6,AGC ON)

B/W: 0.001 Lux @ (F1.6,AGC ON), 0 Lux with light on

Day & Night

Auto (ICR)

Wide Dynamic Range

True WDR

Angle Adjustment

Pan: 0˚ to 360˚, Tilt: 0˚ to 90˚, Rotation: 0˚ to 360˚

Lens Type

Fixed-focal lens, Dual lens

Iris

Fixed Iris

Focal Length

2.4 mm

Max. Aperture

F1.6

Field of View (FOV)

H: 192.4°, V: 80.2°

Detect

53 m (173.9 ft)

Observe

21.2 m (69.6 ft)

Recognize

10.6 m (34.8 ft)

Identify

5.3 m (17.4 ft)

DORI (Detect, Observe, Recognize, and Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances.

Illuminator Type

2 (IR LED), 2 (Warm Light)

Illumination Distance

IR distance up to 30 m (98.4 ft)

Warm light distance up to 20 m (65.6 ft)

Illumination Control

IR mode, White mode, Intelligent mode, None

IR Wavelength

850 nm

Multi-Object Detection

Supports face, human, vehicle detection and capture.

Supports multiple frame modes: Full Frame, Four-corner Frame, and Mosaic.

Intelligent Analysis

Intrusion, Single line crossing, Double line crossing, Loitering, Wrong-way, Illegal parking, and Smart motion detection.

Support alarm triggering by specified target types (human and vehicle).

People Counting

Support

Heat Map

Support

Streaming Capability

3 Streams

Stream/Frame Rate

Splicing mode:

- Stream1: 4224×1848, 3072×1760, 3072×1536, 2880×1440, 2560×1280, 2048×1024 @ 25/30fps

- Stream2: 1920×832, 1536×576 @ 25/30fps

- Stream3: 1920×832, 1280×560 @25/30fps

Multi-channel mode:

- Stream1: 2592×1944,2592×1520, 1920×1080,1280×720 @25/30fps,

- Stream2: D1, VGA, CIF, QVGA @ 25/30fps

Bit Rate Control

CBR/VBR

Bit Rate

Splicing mode:

- Stream1: 500 kbps to 16 Mbps

- Stream2: 200 kbps to 8 Mbps

- Stream3: 200 kbps to 8 Mbps

Multi-channel mode:

- Stream1: 200 kbps to 16 Mbps

- Stream2: 100 kbps to 6 Mbps

Smart Encoder

Support

Region of Interest (ROI)

Support

Audio Compression

G.711 A-law, G.711 μ-law, RAM PCM

Audio Bit Rate

64 Kbps (G.711), 128 Kbps (RAW_PCM)

Image Adjustment

Brightness, Sharpness, Contrast, Saturation adjustable

Scene Setting

Indoor, Outdoor

Exposure Mode

Auto, Manual, Shutter priority

White Balance

Auto, Tungsten, Fluorescent, Daylight, Shadow, Manual

Day/Night Setting

Auto, Day, Night, Timer

Noise Reduction

2D/3D DNR

Image Enhancement

WDR, HLC, BLC, Defog

Privacy Masking

4 areas

Alarm Triggers

IVS, Motion detection, Alarm input, Network alarm, Disk alarm, Day/Night switch alarm, Abnormal sound detection

Event Actions

Alarm record, Alarm output, FTP upload, SMTP upload, Audible alarm output, White light alarm output, Red and blue light alarm

Protocols

IPv4/IPv6, HTTP/HTTPS, DNS, DDNS, DHCP, PPPoE, RTSP/ RTCP/RTP, TCP/UDP, NTP, ARP, UPnP, FTP, SMTP, QoS, ICMP, IGMP, SMTP, 802.1x, SNMP, Multicast

Interoperability

ONVIF (Profile S/T/G/M), SDK, CGI

Max Concurrent Streams

10 channels

User/Host Level

32+ users, 3 levels: Administrator, Operator, Media user

Security

IP address filter, HTTPS, Illegal login lock, IEEE 802.1x

Web Viewer

<IE11, Chrome, Firefox, Microsoft Edge

Network Interface

1 Ethernet (100/1000 Base-T) RJ-45 Connector

Built-in Microphone

Support

Built-in Speaker

Support

Audio Interface

1ch Input, 1ch Output

Alarm Interface

1ch Input, 1ch Output

SD Card Slot

Built-in, up to 1 TB

Reset Button

Support

Language

English, Chinese, Traditional Chinese, Polish, Italian, Portuguese, Spanish, Russian, French, Czech, Hungarian, Japanese, Korean. Default: English

Power Supply

12VDC (-15% to +25%) / PoE (802.3af)

Power Consumption

Typical: 4.2 W (12 VDC) / approx. 5.3 W (PoE)

Max. (IR on + Red/Blue light + Speaker): 8.9 W (12VDC) / approx. 11.2 W (PoE)

Operating Temperature

-40°C to 60°C (-40°F to 140°F )

Operating Humidity

Less than 90% RH

Ingress Protection

IP66

Certifications

CE-EMC

- EN 55032, EN IEC 61000-6-4, EN IEC 61000-3-2, EN 61000-3-3, EN 55035, EN 50130-4

FCC 47 CFR Part 15 Subpart B

Material

Aluminum alloy body, Decoration ring: plastic

Dimensions

Φ140 × 119.2 mm (φ5.51 × 4.69 inch)

Net Weight

0.93 kg (2.05 lb)
