Image Sensor

1/2.8” Progressive Scan CMOS

Max. Resolution

2592(H) × 1944 (V)

Signal System

PAL/NSTC

Electronic Shutter

Auto/Manual, 1/5 to 1/20,000s

Min. illumination

Color: 0.07 Lux @ (F1.6, AGC ON), B/W: 0.007 Lux @ (F1.6, AGC ON)

Day & Night

Auto (ICR)

Wide Dynamic Range

True WDR

Focal Length

5.3 to 159 mm, 30x optical zoom

Max. Aperture

F1.6 to F4.3

Angle of View

H: 56.3° to 2.7°, V: 42.4° to 2.0°

Digital Zoom

16x

Iris Control

Auto/Manual

Focus Control

Auto/Manual/Semi-automatic

Detection

104 to 3,120 m (341.2 to 10,236.2 ft)

Observe

41.6 to 1,248 m (136.5 to 4,094.5 ft)

Recognize

20.8 to 624 m (68.2 to 2,047.2 ft)

Identify

10.4 to 312 m (34.1 to 1,023.6 ft)

DORI (Detect, Observe, Recognize, and Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances.

Multi-Object Detection

Support face, human, vehicle detection and capture

Supports multiple frame modes: Full Frame, Four-corner Frame, and Mosaic.

Smoke and Flame Detection

Support

Intelligent Analysis

Intrusion, Single line crossing, Double line crossing, Loitering, Wrong-way detection, Illegal parking, and Smart motion detection

(support the accurate detection of vehicle and human)

People Counting

Support

Streaming Capability

3 Streams

Stream/Frame Rate

Stream1: 2592×1944, 2592×1520, 1920×1080, 1280×720 @25/30fps

Stream2: D1, VGA, CIF @25/30fps

Stream3: VGA, CIF, QVGA @25/30fps

Bit Rate Control

CBR/VBR

Bit Rate

Stream1: 200 kbps to 12 Mbps

Stream2: 100 kbps to 6 Mbps

Stream3: 100 kbps to 3 Mbps

Smart Encoder

Support

Region of Interest (ROI)

Support

Audio Compression

G.711 A-law, G.711 μ-law, RAW_PCM

Audio Bit Rate

64 kbps (G.711), 128 kbps (RAW_PCM)

Image Adjustment

Brightness, Sharpness, Contrast, Saturation adjustable

Scene Mode

Indoor, Outdoor, Mirror

Exposure Mode

Auto, Manual, Shutter priority, Iris priority

White Balance

Auto, Tungsten, Fluorescent, Daylight, Shadow, Manual

Day/Night Setting

Auto, Day, Night, Timer

Noise Reduction

2D/3D DNR

Image Enhancement

WDR, HLC, BLC, Defog, Anti-shake

Privacy Masking

Support 8 zones, mask color configurable

Alarm Triggers

IVS, Motion detection, Alarm input, Network alarm, Disk alarm, Day/Night switch alarm, Abnormal sound detection

Event Actions

Alarm record, Alarm output, FTP upload, SMTP upload, Audible alarm output

Protocols

IPv4/IPv6, HTTP/HTTPS, DNS, DDNS, DHCP, PPPoE, RTSP/ RTCP/RTP, TCP/UDP, NTP, ARP, UPnP, FTP, SMTP, QoS, ICMP, IGMP, SMTP, 802.1x, SNMP, Multicast

Interoperability

ONVIF (Profile S/T/G/M), SDK, CGI

Max Concurrent Streams

10 channels

User/Host Level

32+ users, 3 levels: Administrator, Operator, Media user

Security

IP address filter, HTTPS, Illegal login lock, IEEE 802.1x

Web Viewer

<IE11, Chrome, Firefox, Microsoft Edge

Network Interface

1 Ethernet (10/100 Base-T) RJ-45 Connector

Audio Interface

1ch Input, 1ch Output

Alarm Interface

1ch Input, 1ch Output

RS-485

Support

CVBS Output

Support

SD Card Slot

Built-in, up to 256 GB

Reset Button

Support

Language

English, Chinese, Traditional Chinese, Polish, Italian, Portuguese, Spanish, Russian, French, Czech, Hungarian, Japanese, Korean. Default: English

Power Supply

12 VDC ± 20%

Power Consumption

Max 7 W

Operating Temperature

-20°C to 60°C (-4°F to 140°F )

Operating Humidity

Less than 90% RH

Ingress Protection

N/A

Certifications

CE-EMC

- EN 55032, EN IEC 61000-6-3, EN IEC 61000-3-2, EN 61000-3-3, EN 55035, EN 50130-4

FCC 47 CFR Part 15 Subpart B

Material

Metal

Dimensions

112.7 × 47.9 × 55.7 mm (4.44 × 1.89 × 2.19 inch)

Net Weight

Approx. 0.28 kg (0.62 lb)
