Image Sensor

Vanadium Oxide Uncooled Focal Plane Arrays

1/2.7" CMOS

Max Resolution

Sensor is 256(H) × 192(V) , Image can be scaled up to 704 × 576

2880(H) × 1620(V)

Pixel Pitch

12μm

N/A

Spectral Range

8 to 14μm

N/A

NETD

≤ 50mK

N/A

Shutter Speed

N/A

1/5 to 1/20,000s

Min Illumination

N/A

Color: 0.05Lux @(F1.6, AGC ON),
B/W: 0.005Lux @(F1.6, AGC ON), 0Lux with IR on

Day & Night

N/A

Auto (ICR)

Lens Type

Fixed lens

Fixed lens

Focal Length

3.5 mm, 7 mm, 10 mm optional

4 mm, 8 mm optional

Max. Aperture

F1.0

F1.6 / F2.0

Field of View (FOV)

3.5 mm,
- H: 48°, V: 36°
7 mm,
- H: 24°, V: 18°
10 mm,
- H: 17°, V: 13°

4 mm,
- H: 92°, V: 46°
8 mm,
- H: 40°, V: 20°

Focus Control

Fixed

Fixed

Type

IR

IR wavelength

850 nm

Distance

4 mm: Up to 35 m (114.83 ft)
8 mm: Up to 50 m (164.04 ft)

Control

Auto / Manual

AI Multi-Target

Supports human/vehicle detection.

Supports human/vehicle detection.

Intelligent Analysis

Intrusion, smart motion detection, single-line crossing, double-line crossing, loitering, wrong-way detection, enter area, and leave area.
- Supports accurate target classification (human/vehicle).

Intrusion, smart motion detection, single-line crossing, double-line crossing, loitering, wrong-way detection, enter area, and leave area.
- Supports accurate target classification (human/vehicle).

Smoke and Flame Detection

N/A

Supported

People Counting

Supported

Supported

Smoking Detection

Supported

N/A

Fire Spot Detection

Supported

N/A

Main Stream

D1 (704×576)

2880×1620, 2560×1440, 2304×1296, 1920×1080, 1280×720

Sub Stream

D1, CIF, 256×192

D1, VGA

Frame Rate

Up to 25fps

Up to 25fps

Bit Rate Control

CBR/VBR

CBR/VBR

Bit Rate

Main Stream: 100 Kbps to 3 Mbps,
Sub Stream: 10 Kbps to 3 Mbps

Main Stream: 100 Kbps to 12 Mbps
Sub Stream: 10 Kbps to 6 Mbps

Smart Encoding

Supported

Supported

Audio Compression

G.711 A-law, G.711 μ-law, RAW_PCM

G.711 A-law, G.711 μ-law, RAW_PCM

Audio Bit Rate

64 Kbps (G.711), 128 Kbps (RAW_PCM)

64 Kbps (G.711), 128 Kbps (RAW_PCM)

Image Adjustment

Brightness, Contrast, Sharpness

Brightness, Saturation, Contrast, Sharpness

Scene Mode

Mirror

Indoor, Outdoor, Mirror

Pseudo-color Setting

Up to 17 colors (White-hot / Black-hot / Rainbow / Iron red / HSV /Bone / Cool / Copper / Fire-hot / Pink / Spring / Summer / Autumn / Winter / Jet / Flame / Rose -Bengal)

N/A

FFC Control

Auto / Manual

N/A

Exposure Mode

N/A

Auto, Manual, Shutter priority

White Balance

N/A

Auto / Tungsten / Fluorescent / Daylight / Shadow

Day/Night Setting

N/A

Auto / Day mode / Night mode / Timer

Noise Reduction

2D/3D DNR

2D/3D DNR

Image Enhancement

N/A

WDR, HLC, BLC, Defog

Wide Dynamic Range

N/A

True WDR 120dB

OSD

Up to 8 OSD

Up to 8 OSD

Privacy Masking

4 areas

4 areas

Temperature Range

-20°C to 150°C (-4°F to 302°F)

Accuracy

±2°C / ±2%

Temperature Detection

3 temperature measurement rule types, 20 rules in total, 1 full screen, 19 others (spot, areas, line).

Temperature Alarm

Temperature difference alarm, Threshold alarm, Temperature rise alarm

Temperature Display

Display in the lower left corner, follow the cursor display of the highest temperature, lowest temperature or average temperature

Response Time

≤ 30ms

Image Fusion

Fusion view of thermal view and overlaid details of the optical channel

Alarm Triggers

IVS, Motion detection, Alarm input, Network alarm, Disk alarm, Abnormal sound detection

Event Actions

Alarm output, Recording, SMTP, FTP upload, Flashlight alarm, Audible alarm output

Protocols

IPv4/IPv6, HTTP/HTTPS, DNS, DDNS, DHCP, PPPOE, RTSP/RTP/RTCP, TCP/UDP, NTP, ARP, UPnP, FTP, SMTP, QoS, 802.1x, SNMP, Multicast

Application Programming Interface

ONVIF (Profile S/T/G/M), CGI, SDK

Max Concurrent Streams

10 channels

User/Host Level

32+ users, 3 levels: Administrator, Operator, Media user

Web Viewer

<IE11, Chrome, Firefox, Microsoft Edge

OS / Firmware Protect

Encrypted firmware, Signed firmware

User Authentication

Digest authentication, Prevent brute-force attack

Network Authentication

IEEE 802.1X (EAP-TLS)

Secure Communication

HTTPS, WSS (WebSocket Secure), SRTP

Access Control

IP-based access control, Auto logout

Data Protect

Encryption credentials

Audit

Access / System / Event Log management

Secure Storage

SDcard partition encrypt (AES-256), Secure element

Supply Chain Security

SBOM

Network Interface

1 × Ethernet (10/100 Base-T), RJ-45 connector

Built-in Speaker

Supported

Audio Interface

1ch input, 1ch output

Alarm Interface

2ch input, 2ch output

Control Interface

1ch RS-485

SD Card Slot

Support microSD card, up to 512GB

Reset Button

Supported

Language

English, Chinese, Traditional Chinese, Polish, Italian, Portuguese, Spanish, Russian, French, Czech, Hungarian, Japanese, Korean. Default: English

Power Supply

12 VDC / 24 VDC / PoE (802.3af)

Power Consumption

Max 12 W

Operating Temperature

-40°C to 60°C (-40°F to 140°F)

Operating Humidity

Less than 95% RH

Ingress Protection

IP66

Certifications

CE-EMC
- EN 55032, EN IEC 61000-6-3, EN IEC 61000-3-2, EN 61000-3-3, EN 55035, EN 50130-4
FCC 47 CFR Part 15 Subpart B

Material

Metal

Dimensions

303 × 95 × 107 mm (11.93 × 3.74 × 4.21 inch)

Net Weight

Approx. 1.38 Kg (3.04 lb) with 3.5mm lens

Detect

4 mm: 72 m (236.22 ft), 8 mm: 146 m (479 ft)

Observe

4 mm: 28.8 m (94.49 ft), 8 mm: 58.4 m (191.6 ft)

Recognize

4 mm: 14.4 m (47.24 ft), 8 mm: 29.2 m (95.8 ft)

Identify

4 mm: 7.2 m (23.62 ft), 8 mm: 14.6 m (47.9 ft)

Thermal Lens

3.5 mm

7 mm

10 mm

Detection (Human: 1.8×0.5 m)

146 m (479.0 ft)

292 m (958.0 ft)

417 m (1,368.1 ft)

Detection (Vehicle: 4×1.5 m)

447 m (1,466.5 ft)

894 m (2933.1 ft)

1,278 m (4,192.9 ft)

Recognition (Human: 1.8×0.5 m)

36 m (118.1 ft)

73 m (239.5 ft)

104 m (341.2 ft)

Recognition (Vehicle: 4×1.5 m)

112 m (367.5 ft)

224 m (734.9 ft)

319 m (1,046.5 ft)

Identification (Human: 1.8×0.5 m)

18 m (59 ft)

36 m (118.1 ft)

52 m (170.6 ft)

Identification (Vehicle: 4×1.5 m)

56 m (183.7 ft)

112 m (367.5 ft)

160 m (524.9 ft)

Note:
Distances are calculated based on Johnson's Criteria.
Detection: Object must be covered by ≥1.5 pixels.
Recognition: Object must be covered by ≥6 pixels.
Identification: Object must be covered by ≥12 pixels.

Lens

3.5 mm

7 mm

10 mm

VCA Detection (Human: 1.8×0.5 m)

30 m (98.4 ft)

60 m (196.9 ft)

103 m (337.9 ft)

VCA Detection (Front/Rear of Vehicle: 4×1.5 m)

35 m (114.8 ft)

70 m (229.7 ft)

230 m (754.6 ft)

Temperature Measurement (1 ×1 m)

58.3 m (191.3 ft)

116.7 m (382.9 ft)

166.7 m (546.9 ft)

Temperature Measurement (0.2×0.2 m)

11.7 m (38.4 ft)

23.3 m (76.4 ft)

33.3 m (109.3 ft)

Fire Detection (0.2×0.2 m)

29.2 m (95.8 ft)

58.3 m (191.3 ft)

83.3 m (273.3 ft)

Smoking Detection

13 m (42.7 ft)

25 m (82 ft)

40 m (131.2 ft)

Note:
Values are for reference only. Actual detection range may vary with atmospheric conditions, target size, and installation environment.
