Image Sensor

1/2.8” Progressive Scan CMOS

Max. Resolution

3MP, 2304(H) × 1296(V)

Electronic Shutter

Auto/Manual, 1/5 to 1/20,000s

Min. illumination

Color: 0.03 Lux @ (F1.2, AGC ON), B/W: 0 Lux with IR

Day & Night

IR cut filter

Wide Dynamic Range

DWDR

Angle Adjustment

Pan: 0˚ to 335˚, Tilt: 0˚ to 75˚, Rotation: 350˚

Lens Type

Fixed lens, Fixed focal

Iris

Fixed Iris

Focal Length

2.8 mm, 4 mm optional

Max. Aperture

F2.0 / F1.6

Field of View (FOV)

2.8 mm:

- H: 103.3°, V: 56.7°

4 mm:

- H: 89°, V: 44.9°

Detect (2.8 mm)

55 m (180.45 ft)

Observe (2.8 mm)

22 m (72.18 ft)

Recognize (2.8 mm)

11 m (36.09 ft)

Identify (2.8 mm)

5.5 m (18.04 ft)

DORI (Detect, Observe, Recognize, and Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances.

Illuminator Type

IR

Illumination Distance

Up to 30 m (98.4 ft)

Illumination On/Off Control

Auto/Manual

IR wavelength

850 nm

Multi-Object Detection

Supports face, human, vehicle detection

Intelligent Analysis

Intrusion, Single line crossing, Double line crossing, Loitering, Wrong-way, and Smart motion detection

Support alarm triggering by specified target types (human and vehicle)

Streaming Capability

3 Streams

Stream/Frame Rate

Stream1: 2304×1296, 1920×1080, 1280×960, 1280×720 @25fps

Stream2: D1, VGA, 640×360,CIF, QVGA @25fps

Stream3: VGA, CIF, QVGA @25fps

Bit Rate Control

CBR/VBR

Bit Rate

Stream1: 100 Kbps to 6 Mbps

Stream2: 100 Kbps to 6 Mbps

Stream3: 100 Kbps to 3 Mbps

Smart Encoder

Support

Region of Interest (ROI)

Off/On (8 Zone, Rectangle)

Image Adjustment

Brightness, Sharpness, Contrast, Saturation adjustable

Scene Setting

Indoor, Outdoor, Mirror, Corridor Mode

Exposure Mode

Auto, Manual, Shutter priority

White Balance

Auto, Tungsten, Fluorescent, Daylight, Shadow, Manual

Day/Night Setting

Auto, Day, Night, Timer

Noise Reduction

2D/3D DNR

Image Enhancement

WDR, HLC, BLC

Privacy Masking

4 areas

Alarm Triggers

IVS, Motion detection, Network alarm, Disk alarm, Day/Night switch alarm

Event Actions

Alarm record, SMTP upload, FTP upload

Protocols

IPv4/IPv6, HTTP/HTTPS, DNS, DDNS, DHCP, PPPoE, RTSP/ RTCP/RTP, TCP/UDP, NTP, ARP, UPnP, FTP, SMTP, QoS, ICMP, IGMP, SMTP, 802.1x, SNMP, Multicast

Interoperability

ONVIF (Profile S/T/G/M), SDK, CGI

Max Concurrent Streams

10 channels

User/Host Level

32+ users, 3 levels: Administrator, Operator, Media user

Security

IP address filter, HTTPS, Illegal login lock, IEEE 802.1x

Web Viewer

<IE11, Chrome, Firefox, Microsoft Edge

Network Interface

1 Ethernet (10/100 Base-T) RJ-45 Connector

SD Card Slot

Built-in, up to 256GB

Reset Button

Support

Language

English, Chinese, Traditional Chinese, Polish, Italian, Portuguese, Spanish, Russian, French, Czech, Hungarian, Japanese, Korean. Default: English

Power Supply

12 VDC (-15% to +25%)/PoE (802.3af)

Power Consumption

Max 4.5 W

Operating Temperature

-30°C to 55°C (-22°F to 131°F )

Operating Humidity

Less than 90% RH

Ingress Protection

IP67, IK10

Certifications

CE-EMC

- EN 55032, EN IEC 61000-6-3, EN IEC 61000-3-2, EN 61000-3-3, EN 55035, EN 50130-4

FCC 47 CFR Part 15 Subpart B

Material

Aluminum alloy body, bubble: plastic

Dimensions

φ110 × 85.4 mm (φ4.33 × 3.36 inch)

Net Weight

0.42 kg (0.93 lb)
