Image Sensor

4 × 1/2.8” Progressive Scan CMOS

Max Resolution

5MP, 2592(H) × 1944(V)

Shutter Speed

1/5 to 1/100,000s

Min Illumination

Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0.001 Lux @ (F1.6, AGC ON), 0 Lux with IR on

Day & Night

Auto (ICR)

Angle Adjustment

Pan: -180˚ to 180˚, Tilt: 0˚ to 130˚, Rotation: 0˚ to 355˚

Lens Type

Varifocal lens, Motorized focal

Focal Length

2.7 to 13.5 mm

Max. Aperture

F1.6

Field of View (FOV)

H: 95.6° to 26.9°, V: 65.4° to 20.5°

Iris

Auto Iris

Detect

68 to 195 m (223.1 to 639.8 ft)

Observe

27.2 to 78 m (89.2 to 255.9 ft)

Recognize

13.6 to 39 m (44.6 to 128.0 ft)

Identify

6.8 to 19.5 m (22.3 to 64.0 ft)

Type

IR

IR wavelength

850 nm

Distance

Up to 40 m (131.2 ft)

Control

Auto/Manual

AI Multi-Target

- Supports face, human, and vehicle detection & capture - Supports human and vehicle attribute detection - Supports multiple frame modes: Full Frame, Four-Corner Frame, Mosaic

Attribute Extraction

Human Attributes: Gender, age, glasses, hat, bag, upper clothing color & style, lower clothing color & style, reflective vest Vehicle Attributes: Type, color, brand, orientation

Intelligent Analysis

Intrusion, smart motion detection, single line crossing, double line crossing, loitering, wrong-way detection, area people limit, perimeter detection, illegal parking, running detection, fall detection, fight detection, enter area, and leave area - Supports accurate target classification (human/vehicle)

People Counting

Supported

Number of Streams

3 Streams

Resolution

Stream1: 2592 × 1944, 2592 × 1520, 1920 × 1080, 1280 × 720 Stream2: D1, VGA, CIF Stream3: VGA, CIF, QVGA

Frame Rate

Up to 25/30fps

Bit Rate Control

CBR/VBR

Bit Rate

Stream1: 200 Kbps to 12 Mbps Stream2: 100 Kbps to 6 Mbps Stream3: 100 Kbps to 3 Mbps

Smart Encoding

Supported

Region of Interest (ROI)

Off / On (8 Zone, Rectangle)

Audio Compression

G.711 A-law, G.711 μ-law, RAW_PCM

Audio Bit Rate

64 Kbps (G.711), 128 Kbps (RAW_PCM)

Image Adjustment

Brightness, Sharpness, Contrast, Saturation adjustable

Scene Mode

Indoor, Outdoor, Mirror, Corridor mode

Exposure Mode

Auto, Manual, Shutter priority

White Balance

Auto, Tungsten, Fluorescent, Daylight, Shadow, Manual

Day/Night Setting

Auto, Day, Night, Timer

Noise Reduction

2D/3D DNR

Image Enhancement

WDR, HLC, BLC, Defog

Wide Dynamic Range

True WDR (120dB)

Privacy Masking

Up to 4 × 4 areas

Alarm Triggers

IVS, Motion detection, Alarm input, Network alarm, Disk alarm, Day/Night switch alarm, Abnormal sound detection

Event Actions

Alarm record, Alarm output, FTP upload, SMTP upload, Snapshot, Audible alarm output

Protocols

IPv4/IPv6, HTTP/HTTPS, DNS, DDNS, DHCP, PPPoE, RTSP/ RTCP/RTP, TCP/UDP, NTP, ARP, UPnP, FTP, SMTP, QoS, ICMP, IGMP, SMTP, 802.1x, SNMP, Multicast

Application Programming Interface

ONVIF (Profile S/T/G/M), SDK, CGI

Max Concurrent Streams

10 channels

User/Host Level

32+ users, 3 levels: Administrator, Operator, Media user

Web Viewer

<IE11, Chrome, Firefox, Microsoft Edge

OS / Firmware Protect

Encrypted firmware, Secure boot, Signed firmware

User Authentication

Digest authentication, Prevent brute-force attack

Network Authentication

IEEE 802.1X (EAP-TLS)

Secure Communication

HTTPS, WSS(WebSocket Secure), SRTP

Access Control

IP-based access control, Auto logout

Data Protect

Encryption credentials

Audit

Access / System / Event Log management

Secure Storage

SDcard partition encrypt(AES-256), Secure element

Supply Chain Security

SBOM

Network Interface

1 × Ethernet (10/100 Base-T), RJ-45 connector

Built-in Microphone

Supported

Audio Interface

1ch Input, 1ch Output

Alarm Interface

4ch Input, 2ch Output

RS-485

1 RS-485

CVBS Output

Supported

SD Card Slot

Built-in microSD card slot, up to 1 TB

Reset Button

Supported

Language

English, Chinese, Traditional Chinese, Polish, Italian, Portuguese, Spanish, Russian, French, Czech, Hungarian, Japanese, Korean. Default: English

Power Supply

12 VDC (-15% to +25%) / PoE+ (802.3at)

Power Consumption

Typical: 10.8 W (12 VDC) / approx. 13.5 W (PoE) Max (IR on): 20.2 W (12 VDC) / approx. 25.3 W (PoE)

Operating Temperature

-40°C to 60°C (-40°F to 140°F )

Operating Humidity

Less than 95% RH

Ingress Protection

IP67, IK10

Certifications

CE-EMC - EN 55032, EN IEC 61000-6-4, EN IEC 61000-3-2, EN 61000-3-3, EN 55035, EN 50130-4 FCC 47 CFR Part 15 Subpart B

Material

Aluminum alloy body, bubble: plastic

Dimensions

Φ282 × 206.3 mm (φ11.1 × 8.12 inch) , (Bracket not included)

Net Weight

Approx. 4 kg (8.82 lb), (Bracket not included)
