Radar | |
Radar Type | FMCW (Frequency Modulated Continuous Wave) |
Operating Frequency | 24–24.25 GHz |
Update Rate | 8 Hz |
Detectable Targets | Humans, vehicles |
Detection Range | Human (RCS 1.0 m²): Up to 450 m |
Detection Angle | Azimuth: 90°, Elevation: 13° |
Target Capacity | Up to 32 targets |
Range Accuracy | ±0.75 m |
Range Resolution | 1.5 m |
Angular Accuracy | ±1° |
Speed Range | 0.5–30 m/s |
Speed Accuracy | ±0.03 m/s |
Speed Resolution | 0.06 m/s |
Network | |
Protocols | HTTP, DNS, NTP, TCP, UDP, DHCP, ARP, SSH |
Interface | |
Network Interface | 1 × RJ45 (10/100 Mbps, PoE+) |
Alarm Interface | 1 × Digital Output |
RS-485 | 1 |
General | |
Power Supply | 12 V DC / PoE+ (IEEE 802.3at) |
Power Consumption | ≤ 17 W |
Operating Temperature | -40 °C to +65 °C (-40 °F to +149 °F) |
Storage Temperature | -40 °C to +85 °C (-40 °F to +185 °F) |
Ingress Protection | IP66 |
Dimensions | 235.1 × 175.1 × 53.7 mm (9.26 × 6.90 × 2.12 in.) |
Net Weight | Approx. 1.65 kg (3.64 lb) |
