Radar | |
Radar Type | FMCW (Frequency Modulated Continuous Wave) |
Operating Frequency | 24.00–24.25 GHz |
Update Rate | 10 Hz |
Detectable Targets | Large vessels, boats, fishing boats, speedboats |
Detection Range | Small vessel (≤10 m): Up to 1,500 m |
Detection Angle | Azimuth: 90°, Elevation: 13° |
Target Capacity | Up to 32 targets |
Range Accuracy | ±2 m |
Range Resolution | 4 m |
Angular Accuracy | ±1° |
Speed Range | 0.5–30 m/s |
Speed Accuracy | ±0.03 m/s |
Speed Resolution | 0.06 m/s |
Network | |
Protocols | HTTP, DNS, NTP, TCP, UDP, DHCP, ARP, SSH |
Interface | |
Network Interface | 1 × RJ45 (10/100/1000 Mbps) |
Alarm Interface | 1 × Relay Output, 1 × Digital Output, 1 × Digital Input |
RS-485 | 1 |
General | |
Power Supply | 12 V DC /2.3A |
Power Consumption | ≤ 28 W |
Operating Temperature | -40 °C to 70 °C (-40 °F to +158 °F) |
Storage Temperature | -40 °C to 85 °C (-40 °F to +185 °F) |
Ingress Protection | IP66 |
Dimensions | 234 × 315 × 49.0 mm (9.22 × 12.41 × 1.93 in.) |
Net Weight | Approx. 3.5 kg (7.72 lb) |
