Image Sensor

Vanadium Oxide Uncooled Focal Plane Arrays

Max Resolution

160(H) × 120(V) , Image can be scaled up to 704 × 576

Pixel Pitch

17 µm

Spectral Range

8 to 14 µm

NETD

≤ 50mK

Lens Type

Fixed lens

Focal Length

1.5 mm, 2.1 mm optional

Max. Aperture

F1.0

Field of View (FOV)

1.5 mm, H: 114°, V: 82° 2.1 mm, H: 90°, V: 64°

Focus Control

Focus-free

AI Multi-Target

Supports human/vehicle detection.

Intelligent Analysis

Smart motion detection, intrusion detection, single/double line crossing, loitering, wrong-way detection, entry/exit area detection, and fall detection. - Supports accurate target classification (human/vehicle)

People Counting

Supported

Smoking Detection

Supported

Fire Spot Detection

Supported

Main Stream

D1 (704×576)

Sub Stream

CIF, 256×192

Frame Rate

Up to 25fps

Bit Rate Control

CBR/VBR

Bit Rate

Main stream: 100 Kbps to 6 Mbps, Sub stream: 10 Kbps to 1.5 Mbps

Smart Encoding

Supported

Audio Compression

G.711 A-law, G.711 μ-law, RAW_PCM

Audio Bit Rate

64 Kbps (G.711), 128 Kbps (RAW_PCM)

Image Adjustment

Brightness, Contrast, Sharpness

Scene Mode

Mirror

Pseudo-color Setting

Up to 17 colors (White-hot / Black-hot / Rainbow / Iron red / HSV /Bone / Cool / Copper / Fire-hot / Pink / Spring / Summer / Autumn / Winter / Jet / Flame / Rose -Bengal)

FFC Control

Auto / Manual

Noise Reduction

2D/3D DNR

OSD

Up to 8 OSD

Privacy Masking

Up to 4 areas

Temperature Range

-20°C to 150°C (-4°F to 302°F)

Accuracy

±8°C (depending on emissivity, distance, ambient temperature settings, etc.)

Temperature Detection

Supports 3 rule types (spot, line, area); up to 20 rules in total, including 1 full-screen and 19 spot/line/area rules

Temperature Alarm

Supports threshold alarm, temperature difference alarm, section alarm, and temperature rise alarm.

Temperature Display

Display in the lower left corner; follow the cursor display of the highest temperature, lowest temperature or average temperature

Alarm Triggers

IVS, Temperature anomaly, Motion detection, Alarm Input, Disk alarm, Network alarm, Audio detection, Voice wake up alarm

Event Actions

Alarm out, Alarm record, SMTP, FTP upload, Red and blue light alarm, Audible alarm output

Protocols

IPv4/IPv6, HTTP/HTTPS, DNS, DDNS, DHCP, PPPoE, RTSP/ RTCP/RTP, TCP/UDP, NTP, ARP, UPnP, FTP, SMTP, QoS, ICMP, IGMP, SMTP, 802.1x, SNMP, Multicast

Application Programming Interface

ONVIF (Profile S/T/G/M), SDK, CGI

Max Concurrent Streams

10 channels

User/Host Level

32+ users, 3 levels: Administrator, Operator, Media user

Web Viewer

<IE11, Chrome, Firefox, Microsoft Edge

OS / Firmware Protect

Encrypted firmware, Signed firmware

User Authentication

Digest authentication, Prevent brute-force attack

Network Authentication

IEEE 802.1X (EAP-TLS)

Secure Communication

HTTPS, WSS (WebSocket Secure), SRTP

Access Control

IP-based access control, Auto logout

Data Protect

Encryption credentials

Audit

Access / System / Event Log management

Secure Storage

SDcard partition encrypt(AES-256), Secure element

Supply Chain Security

SBOM

Network Interface

1 × Ethernet (10/100 Base-T), RJ-45 connector

Built-in Microphone

Supported

Built-in Speaker

Supported

Alarm Interface

1ch input, 1ch output

Control Interface

1ch RS-485

CVBS Output

Supported

SD Card Slot

Built-in Micro SD slot, supports up to 1TB

Reset Button

Supported

Language

English, Chinese, Traditional Chinese, Polish, Italian, Portuguese, Spanish, Russian, French, Czech, Hungarian, Japanese, Korean. Default: English

Power Supply

12 VDC / PoE (802.3af)

Power Consumption

Max 4 W

Operating Temperature

-40°C to 60°C (-40°F to 140°F)

Operating Humidity

≤95% RH (non-condensing)

Ingress Protection

IP66, IK10-rate housing

Certifications

CE-EMC - EN 55032, EN IEC 61000-6-4, EN IEC 61000-3-2, EN 61000-3-3, EN 55035, EN 50130-4 FCC 47 CFR Part 15 Subpart B

Material

Metal

Dimensions

φ110 × 91.8 mm (4.33 × 3.61 inch)

Net Weight

Approx. 650 g (1.43 lb)

Thermal Lens

1.5 mm

2.1 mm

Detection (Human: 1.8×0.5 m)

44.1 m (144.7 ft)

61.6 m (202.0 ft)

Detection (Vehicle: 4×1.5 m)

135.4 m (444.1 ft)

189.5 m (621.7 ft)

Recognition (Human: 1.8×0.5 m)

11.0 m (36.1 ft)

15.4 m (50.5 ft)

Recognition (Vehicle: 4×1.5 m)

33.9 m (111.2 ft)

47.4 m (155.6 ft)

Identification (Human: 1.8×0.5 m)

5.5 m (18.0 ft)

7.7 m (25.3 ft)

Identification (Vehicle: 4×1.5 m)

16.9 m (55.4 ft)

23.7 m (77.8 ft)

Note:
Distances are calculated based on Johnson's Criteria.
Detection: Object must be covered by ≥1.5 pixels.
Recognition: Object must be covered by ≥6 pixels.
Identification: Object must be covered by ≥12 pixels.

Temperature Measurement (1 ×1 m)

17.6 m (57.7 ft)

24.7 m (81.0 ft)

Temperature Measurement (0.2×0.2 m)

3.5 m (11.5 ft)

4.9 m (16.1 ft)

Fire Detection (1×1 m)

44 m (144.4 ft)

62 m (203.4 ft)

Fire Detection (0.2×0.2 m)

8.8 m (28.9 ft)

12.4 m (40.7 ft)

Note:
Values are for reference only. Actual detection range may vary with atmospheric conditions, target size, and installation environment.
