Image Sensor

1/2.8” Progressive Scan CMOS

Max Resolution

4MP, 2592(H) × 1520(V)

Shutter Speed

1/5 to 1/100,000s

Min Illumination

Color: 0.03 Lux @ (F1.6, AGC ON), B/W: 0.008 @ (F1.6, AGC ON)

Day & Night

Auto (ICR)

S/N Ratio

55dB

Lens Type

C/CS mount

Iris

Fixed Iris, Auto Iris

Smart Function

License plate recognition (LPR); Vehicle attribute recognition (type, color, direction)

Vehicle Type

Car, SUV, Van, Minivan, Pickup, Bus, Truck, MPV, Sports Car

Vehicle Color

Blue, Yellow, Black, White, Green, Red, Gray, Brown, Gold, Orange

Vehicle Direction

Front-facing, Rear-facing

LPR Detection Speed

Up to 60 km/h

LPR Region Support

Default Support: Australia, Chile, Indonesia, Malaysia, Oman, Saudi Arabia, South Africa.

Optional (Customized): Other countries/regions upon request

White/Black List

Up to 5,000 records

LPR Smart Search

Supported

Intelligent Analysis

Intrusion, Single line crossing, Double line crossing, Wrong-way detection, Illegal parking, and Smart motion detection.

Support alarm triggering by specified target types (vehicle)

Number of Streams

3 Streams

Resolution

Stream1: 2592×1520, 2560×1440, 2304×1296, 1920×1080, 1280×720

Stream2: D1, VGA, 640×360, CIF, QVGA

Stream3: VGA, CIF, QVGA

Frame Rate

Up to 50/60fps

Bit Rate Control

CBR/VBR

Bit Rate

Stream1: 200 Kbps to 12 Mbps

Stream2: 100 Kbps to 6 Mbps

Stream3: 100 Kbps to 3 Mbps

Smart Encoding

Supported

Region of Interest (ROI)

8 areas

Audio Compression

G.711 A-law, G.711 μ-law, RAW_PCM

Audio Bit Rate

64 Kbps (G.711), 128 Kbps (RAW_PCM)

Image Adjustment

Brightness, Sharpness, Contrast, Saturation

Scene Mode

Indoor, Outdoor, Mirror, Corridor mode

Exposure Mode

Auto, Manual, Shutter priority

White Balance

Auto, Tungsten, Fluorescent, Daylight, Shadow, Manual

Day/Night Setting

Auto, Day mode, Night mode, Time

Noise Reduction

2D/3D DNR

Image Enhancement

WDR, HLC, BLC, Defog

Wide Dynamic Range

True WDR (120dB)

Privacy Masking

4 areas

Alarm Triggers

IVS, Motion detection, Alarm input, Network alarm, Disk alarm, Day/Night switch alarm, Abnormal sound detection

Event Actions

Alarm record, Alarm output, FTP upload, SMTP upload, Snapshot, Audible alarm output

Protocols

IPv4/IPv6, HTTP/HTTPS, DNS, DDNS, DHCP, PPPoE, RTSP/ RTCP/RTP, TCP/UDP, NTP, ARP, UPnP, FTP, SMTP, QoS, ICMP, IGMP, SMTP, 802.1x, SNMP, Multicast

Application Programming Interface

ONVIF (Profile S/T/G/M), SDK, CGI

Max Concurrent Streams

10 channels

User/Host Level

32+ users, 3 levels: Administrator, Operator, Media user

Web Viewer

<IE11, Chrome, Firefox, Microsoft Edge

OS / Firmware Protect

Encrypted firmware, Signed firmware

User Authentication

Digest authentication, Prevent brute-force attack

Network Authentication

IEEE 802.1X (EAP-TLS)

Secure Communication

HTTPS, WSS (WebSocket Secure), SRTP

Access Control

IP-based access control, Auto logout

Data Protect

Encryption credentials

Audit

Access / System / Event Log management

Secure Storage

SDcard partition encrypt (AES-256), Secure element

Supply Chain Security

SBOM

Network Interface

1 × Ethernet (10/100 Base-T), RJ-45 connector

Built-in Microphone

Supported

Audio Interface

1 × Input; 1 × Output

Alarm Interface

1 × Input; 1 × Output

Control Interface

1 × RS-485

CVBS Output

1 × BNC

SD Card Slot

Built-in microSD card slot, up to 1 TB

Reset Button

Supported

Language

English, Chinese, Traditional Chinese, Polish, Italian, Portuguese, Spanish, Russian, French, Czech, Hungarian, Japanese, Korean. Default: English

Power Supply

12 VDC / 24 VAC (-10% to +25%) / PoE (802.3af)

Power Consumption

Max 3 W

Operating Temperature

-30°C to 50°C (-22°F to 122°F )

Operating Humidity

Less than 90% RH

Ingress Protection

N/A

Certifications

CE-EMC

- EN 55032, EN IEC 61000-6-4, EN IEC 61000-3-2, EN 61000-3-3, EN 55035, EN 50130-4

FCC 47 CFR Part 15 Subpart B

Material

Aluminum alloy

Dimensions

152.9 × 74.4 × 69.7 mm (6.02 × 2.93 × 2.74 inch)

Net Weight

Approx. 0.4 kg (0.88 lb)
