Image Sensor

1/2.7” Progressive Scan CMOS

Max. Resolution

8MP, 3840(H) × 2160(V)

Electronic Shutter

Auto/Manual, 1/5 to 1/20,000s

Min. illumination

Color: 0.01 Lux @ (F1.6, AGC ON), B/W: 0 Lux with light on

Day & Night

IR cut filter

Wide Dynamic Range

True WDR

Angle Adjustment

Pan: 0˚ to 355˚, Tilt: 0˚ to 85˚, Rotation: 0˚ to 360˚

Lens Type

Fixed lens, fixed focal

Iris

Fixed Iris

Focal Length

2.8 mm, 4 mm optional

Max. Aperture

F1.6

Field of View (FOV)

2.8 mm

- H: 109.5°, V: 59.8°

4 mm

- H: 91.5°, V: 46.3°

Lens

Detect

Observe

Recognize

Identify

2.8mm

84.2 m (276.2 ft)

33.7 m (110.6 ft)

16.8 m (55.1 ft)

8.4 m (27.6 ft)

4 mm

113 m (370.7 ft)

45.2 m (148.3 ft)

22.6 m (74.1 ft)

11.3 m (37.1 ft)

DORI (Detect, Observe, Recognize, and Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances.

Illuminator Type

IR LED, Warm light

Illumination Distance

IR distance up to 30 m (98.4 ft)

Warm light distance up to 20 m (65.6 ft)

Illumination On/Off Control

IR mode, White mode, Intelligent mode, None

IR wavelength

850 nm

Multi-Object Detection

Supports face, human, vehicle detection

Intelligent Analysis

Intrusion, Single line crossing, Double line crossing, Loitering, Wrong-way, Illegal parking, and Smart motion detection

Support alarm triggering by specified target types (human and vehicle)

People Counting

Support

Streaming Capability

3 Streams

Stream/Frame Rate

Stream1: 3840×2160, 2880×1620, 2592×1520, 2560×1440, 2304×1296, 1920×1080, 1280×720 @25fps

Stream2: D1, VGA, CIF @ 25fps

Stream3: VGA, CIF, QVGA @ 25fps

(Enable WDR is 20fps)

Bit Rate Control

CBR/VBR

Bit Rate

Stream1: 200 Kbps to 16 Mbps

Stream2: 100 Kbps to 6 Mbps

Stream3: 100 Kbps to 3 Mbps

Region of Interest

Off/On (8 areas, Rectangle)

Smart Encode

Support

Audio Compression

G.711 A-law, G.711 μ-law, RAM PCM

Audio Bit Rate

64 Kbps (G.711), 128 Kbps (RAW_PCM)

Image Adjustment

Brightness, Sharpness, Contrast, Saturation adjustable

Scene Setting

Indoor, Outdoor, Mirror, Corridor Mode

Exposure Mode

Auto, Manual, Shutter priority

White Balance

Auto, Tungsten, Fluorescent, Daylight, Shadow, Manual

Day/Night Setting

Auto, Day, Night, Timer

Noise Reduction

2D/3D DNR

Image Enhancement

WDR, HLC, BLC, Defog

Privacy Masking

4 areas

Alarm Triggers

IVS, Motion detection, Network alarm, Disk alarm, Day/Night switch alarm, Abnormal sound detection

Events Actions

Alarm record,  FTP upload, SMTP upload, White light alarm output

Protocols

IPv4/IPv6, HTTP/HTTPS, DNS, DDNS, DHCP, PPPoE, RTSP/ RTCP/RTP, TCP/UDP, NTP, ARP, UPnP, FTP, SMTP, QoS, ICMP, IGMP, SMTP, 802.1x, SNMP, Multicast

Interoperability

ONVIF (Profile S/T/G/M), SDK, CGI

Max Concurrent Streams

10 channels

User/Host Level

32+ users, 3 levels: Administrator, Operator, Media user

Security

IP address filter, HTTPS, Illegal login lock, IEEE 802.1x

Web Viewer

<IE11, Chrome, Firefox, Microsoft Edge

Network Interface

1 Ethernet (10/100 Base-T) RJ-45 Connector

Built-in Microphone

Support

SD Card Slot

Built-in, up to 1 TB

Reset Button

Support

Language

English, Chinese, Traditional Chinese, Polish, Italian, Portuguese, Spanish, Russian, French, Czech, Hungarian, Japanese, Korean. Default: English

Power Supply

12 VDC (-15% to +25%)/PoE (802.3af)

Power Consumption

Typical: 2 W (IR off, 12 VDC) / approx. 2.5 W (PoE)

Max: 3.6 W (Light on, 12 VDC) / approx. 4.5 W (PoE)

Operating Temperature

-30°C to 60°C (-22°F to 140°F )

Operating Humidity

Less than 90% RH

Ingress Protection

IP66

Certifications

CE-EMC

- EN 55032, EN IEC 61000-6-4, EN IEC 61000-3-2, EN 61000-3-3, EN 55035, EN 50130-4

FCC 47 CFR Part 15 Subpart B

Material

Aluminum alloy body + Plastic

Dimensions

Φ111 × 95 mm (Φ4.37 × 3.74 inch)

Net Weight

0.38 kg (0.84 lb)
