Image Sensor

1/3” Progressive Scan CMOS

Max Resolution

5MP, 2560(H) × 1920(V)

Shutter Speed

1/5 to 1/20,000s

Min Illumination

Color: 0.01 Lux @ (F1.6, AGC ON),
B/W: 0.005 Lux @ (F1.6, AGC ON), 0 Lux with illuminator on

Day & Night

Auto (ICR)

Angle Adjustment

Pan: 0˚ to 360˚, Tilt: 5˚ to 75˚, Rotation: 0˚ to 360˚

Lens Type

Varifocal lens, motorized focal

Focal Length

2.7 to 13.5 mm

Max. Aperture

F1.6

Field of View (FOV)

H: 90° to 29.8°, V: 48.3° to 16.8°

Iris

Fixed Iris

Type

IR, Warm light

IR wavelength

850nm

Distance

IR distance up to 30 m (98.4 ft)
Warm light distance up to 20 m (65.6 ft)

Control

IR mode, White mode, Intelligent mode, None

AI Multi-Target

Supports face, human, and vehicle detection.

Intelligent Analysis

Intrusion, smart motion detection, single line crossing, double line crossing, loitering, wrong-way detection, and illegal parking.
- Supports accurate target classification (human/vehicle)

People Counting

Supported

Number of Streams

3 Streams

Resolution

Stream1: 2560×1920, 2560×1440, 2304×1296, 1920×1080, 1280×720
Stream2: D1, VGA, CIF
Stream3: VGA, CIF, QVGA

Frame Rate

Up to 25fps

Bit Rate Control

CBR/VBR

Bit Rate

Stream1: 200 Kbps to 12 Mbps
Stream2: 100 Kbps to 6 Mbps
Stream3: 100 Kbps to 3 Mbps

Smart Encoding

Supported

Region of Interest (ROI)

Off/On (8 areas, Rectangle)

Audio Compression

G.711 A-law, G.711 μ-law, RAW_PCM

Audio Bit Rate

64 Kbps (G.711), 128 Kbps (RAW_PCM)

Image Adjustment

Brightness, Sharpness, Contrast, Saturation adjustable

Scene Mode

Indoor, Outdoor, Mirror, Corridor mode

Exposure Mode

Auto, Manual, Shutter priority

White Balance

Auto, Tungsten, Fluorescent, Daylight, Shadow, Manual

Day/Night Setting

Auto, Day, Night, Timer

Noise Reduction

2D/3D DNR

Image Enhancement

HLC, BLC, Defog, WDR

Wide Dynamic Range

DWDR

Privacy Masking

4 areas

Alarm Triggers

IVS, Motion detection, Network alarm, Disk alarm, Day/Night switch alarm, Abnormal sound detection

Event Actions

Alarm record, FTP upload, SMTP upload, White light alarm output, Audible alarm output

Protocols

IPv4/IPv6, HTTP/HTTPS, DNS, DDNS, DHCP, PPPoE, RTSP/ RTCP/RTP, TCP/UDP, NTP, ARP, UPnP, FTP, SMTP, QoS, ICMP, IGMP, SMTP, 802.1x, SNMP, Multicast

Application Programming Interface

ONVIF (Profile S/T/G/M), SDK, CGI

Max Concurrent Streams

4 channels

User/Host Level

Up to 32 users; 3 levels: Administrator, Operator, and Media User

Web Viewer

<IE11, Chrome, Firefox, Microsoft Edge

OS / Firmware Protect

Encrypted firmware, Signed firmware

User Authentication

Digest authentication, Prevent brute-force attack

Network Authentication

IEEE 802.1X (EAP-TLS)

Secure Communication

HTTPS, WSS (WebSocket Secure), SRTP

Access Control

IP-based access control, Auto logout

Data Protect

Encryption credentials

Audit

Access / System / Event Log management

Secure Storage

SDcard partition encrypt (AES-256), Secure element

Supply Chain Security

SBOM

Network Interface

1 × Ethernet (10/100 Base-T), RJ-45 connector

Built-in Microphone

Supported

Built-in Speaker

Supported

SD Card Slot

Built-in microSD card slot, up to 1 TB

Reset Button

Supported

Language

English, Chinese, Traditional Chinese, Polish, Italian, Portuguese, Spanish, Russian, French, Czech, Hungarian, Japanese, Korean. Default: English

Power Supply

12 VDC (-15% to +25%)/PoE (802.3af)

Power Consumption

Typical: 1.7 W (12 VDC) / approx. 2.2 W (PoE)
Max (Light on + Focus): 4.5 W (12 VDC) / approx. 5.7 W (PoE)Max (Light on + Focus + Speaker): 6.1 W (12 VDC) / approx. 7.7 W (PoE)

Operating Temperature

-25°C to 55°C (-13°F to 131°F )

Operating Humidity

Less than 90% RH

Ingress Protection

IP66

Certifications

CE-EMC
- EN 55032, EN IEC 61000-6-4, EN IEC 61000-3-2, EN 61000-3-3, EN 55035, EN 50130-4
FCC 47 CFR Part 15 Subpart B

Material

Aluminum alloy body, Decoration ring: plastic

Dimensions

φ142.4 × 124.2 mm (φ5.61 × 4.89 inch)

Net Weight

Approx. 750 g (1.65 lb), with speaker

Detect

94 to 274 m (308.4 to 899.0 ft)

Observe

37.6 to 109.6 m (37.6 to 359.6 ft)

Recognize

18.8 to 54.8 m (61.7 to 179.8 ft)

Identify

9.4 to 27.4 m (30.8 to 89.9 ft)
