Image Sensor

1/2.7” Progressive Scan CMOS

Max Resolution

2880(H)×1620(V)

Shutter Speed

1/5 to 1/20,000s

Min Illumination

Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0.001 Lux @ (F1.6, AGC ON), 0 Lux with light

Day & Night

Auto (ICR)

S/N Ratio

52 dB

Focal Length

2.7 to 13.5 mm, 5x optical zoom

Max. Aperture

F1.66 to F3.03

Field of View (FOV)

H: 109.2° to 31.0°, V: 55.8° to 17.4°

Digital Zoom

16x

Iris

Auto / Manual

Focus Control

Auto / Manual

Detect

66 to 203 m (216.5 to 666.0 ft)

Observe

26.4 to 81.2 m (86.6 to 266.4 ft)

Recognize

13.2 to 40.6 m (43.3 to 133.2 ft)

Identify

6.6 to 20.3 m (21.7 to 66.6 ft)

Type

IR

IR wavelength

850 nm

Distance

Up to 30 m (98.4 ft)

Control

Auto / Manual

Multi-Object Detection

- Supports face, human, and vehicle detection & capture - Supports human and vehicle attribute detection - Supports multiple frame modes: Full Frame, Four-Corner Frame, Mosaic

Attribute Extraction

Human Attributes: Gender, age, glasses, hat, bag, upper clothing color & style, lower clothing color & style, reflective vest Vehicle Attributes: Type, color, brand, orientation

Intelligent Analysis

Intrusion detection, smart motion detection, single line crossing, double line crossing, loitering, wrong-way detection, area people limit, perimeter detection, illegal parking, running detection, fall detection, fight detection - Supports accurate target classification (human/vehicle)

Smoke and Flame Detection

Supported

People Counting

Supported

Number of Streams

3 Streams

Resolution

Stream1: 2880×1620, 2304×1296, 1920×1080, 1280×720 Stream2: D1, VGA, 640×360, CIF, QVGA Stream3: VGA, CIF, QVGA

Frame Rate

Up to 25/30fps

Bit Rate Control

CBR/VBR

Bit Rate

Stream1: 200 kbps to 12 Mbps Stream2: 100 kbps to 6 Mbps Stream3: 100 kbps to 3 Mbps

Smart Encoding

Supported

Region of Interest (ROI)

Supported

Audio Compression

G.711 A-law, G.711 μ-law, RAW_PCM

Audio Bit Rate

64 kbps (G.711), 128 kbps (RAW_PCM)

Image Adjustment

Brightness, Sharpness, Contrast, Saturation adjustable

Exposure Mode

Auto, Manual, Shutter priority, Iris priority

White Balance

Auto, Tungsten, Fluorescent, Daylight, Shadow, Manual

Day/Night Setting

Auto, Day, Night, Timer

Noise Reduction

2D/3D DNR

Image Enhancement

HLC, BLC, Defog, WDR

Wide Dynamic Range

True WDR (120dB)

Privacy Masking

Up to 40 ares, mask color configurable

Pan/Tilt Range

Pan: 0° to 350° endless, Tilt: 7° to +90°

Pan Speed

Pan speed: 0.1° to 60°/s, preset speed: 60°/s

Tilt Speed

Tilt speed: 0.1° to 60°/s, preset speed: 60°/s

Preset Accuracy

≤ 0.5°

Preset

400

Track

6 Track

Scan

12 Scan

Tour

12 Tour (up to 32 presets each tour)

Intelligent Tracking

Supported, Object auto tracking (Person/Vehicle)

Power-Off Memory

Supported

3D Positioning

Supported

PTZ Status Display

Supported

Idle Motion

The time can be set (1-240 minutes), and functions such as preset positions, patrols, scans, and tracks can be run.

Alarm Triggers

IVS, Motion detection, Alarm input, Network alarm, Disk alarm, Day/Night switch alarm, Abnormal sound detection

Event Actions

Alarm record, Alarm output, FTP upload, SMTP upload, Snapshot, Linkage tracking, Audible alarm output

Protocols

IPv4/IPv6, HTTP/HTTPS, DNS, DDNS, DHCP, PPPoE, RTSP/ RTCP/RTP, TCP/UDP, NTP, ARP, UPnP, FTP, SMTP, QoS, ICMP, IGMP, SMTP, 802.1x, SNMP, Multicast

Application Programming Interface

ONVIF (Profile S/T/G/M), SDK, CGI

Max Concurrent Streams

10 channels

User/Host Level

32+ users, 3 levels: Administrator, Operator, Media user

Web Viewer

<IE11, Chrome, Firefox, Microsoft Edge

OS / Firmware Protect

Encrypted firmware, Secure boot, Signed firmware

User Authentication

Digest authentication, Prevent brute-force attack

Network Authentication

IEEE 802.1X (EAP-TLS)

Secure Communication

HTTPS, WSS (WebSocket Secure), SRTP

Access Control

IP-based access control, Auto logout

Data Protect

Encryption credentials

Audit

Access / System / Event Log management

Secure Storage

SDcard partition encrypt (AES-256), Secure element

Supply Chain Security

SBOM

Network Interface

1 × Ethernet (10/100 Base-T), RJ-45 connector

Built-in Microphone

Supported

Audio Interface

1ch input, 1ch output

Alarm Interface

1ch input, 1ch output

SD Card Slot

Built-in microSD card slot, up to 1 TB

Reset Button

Supported

Language

English, Chinese, Traditional Chinese, Polish, Italian, Portuguese, Spanish, Russian, French, Czech, Hungarian, Japanese, Korean. Default: English

Power Supply

12 VDC / PoE (802.3af)

Power Consumption

Max 12W

Operating Temperature

-30°C to 60°C (-22°F to 140 °F)

Operating Humidity

Less than 95% RH

Ingress Protection

IP66

Certifications

CE-EMC - EN 55032, EN IEC 61000-6-4, EN IEC 61000-3-2, EN 61000-3-3, EN 55035, EN 50130-4 FCC 47 CFR Part 15 Subpart B

Material

Aluminum alloy body, bubble: plastic

Dimensions

φ117.2 × 99.3 mm (φ4.61 × 3.9 inch)

Net Weight

Approx. 700g (1.54 lb)
