IP Camera Input

64 Channel

Incoming Bandwidth

640 Mbps

Outgoing Bandwidth

640 Mbps

HDMI 1 Output

7680 × 4320, 3840 × 2160, 1920 × 1080, 1280 × 1024, 1024 × 768

HDMI 2 Output

3840 × 2160, 1920 × 1080, 1280 × 1024, 1024 × 768

HDMI 3 Output

3840 × 2160, 1920 × 1080, 1280 × 1024, 1024 × 768

HDMI 4 Output

3840 × 2160, 1920 × 1080, 1280 × 1024, 1024 × 768

VGA Output

1920 × 1080, 1280 × 1024, 1024 × 768

Different Source Output

Up to 4 channels

Decoding Capacity

Up to 48-ch 1080P

Dual Stream

Yes

Multi-screen Display

HDMI 1: 1 / 4 / 8 / 9 / 16 / 32 / 36 / 64

HDMI 2: 1 / 4 / 8 / 9 / 16

HDMI 3: 1 / 4 / 8 / 9 / 16

HDMI 4 / VGA: 1 / 4 / 8 / 9 / 16

Face Comparison

Real-time captured and display faces comparison results (stranger, channel, similarity)

Multi-objective

Real-time captured and display vehicle, human body, non-motor vehicle, license plates image

Smart Search

Time, Properties, Pictures, License plate

Trigger Events

Buzzer, Alarm push, Email, Alarm Out, Compare the result simultaneously, etc.

Resolution

12MP, 8MP, 6MP, 5MP, 4MP, 3MP, 1080P, 720P,  D1 etc.

Recording Mode

Manual, Schedule (Regular, Continuous), Event

Trigger Events

Motion Detection, Video Loss, Alarm in, IVS

Sync Playback

16/9/4/1

Search Mode

Time /Date, Alarm, Picture grid, Event

Backup Mode

USB Device, Network, eSATA, NAS

General Alarm

Motion Detection, Video Loss, Alarm in, Alarm out

Intelligent Analysis

(By Camera)

Smoking Detection, Smoke and Fire Detection, Fire Spot Detection, Intrusion, Single Line Crossing, Double Line Crossing, Loitering, Wrong-way, Illegal Parking, People Counting, Smart motion detection, Enter Area, Leave Area, etc.

Abnormal Alarm

Disk Alarm, IP Address Conflict, Network Disconnect

Intelligent Analysis

(By NVR)

4-ch intrusion detection, support the accurate detection of human and vehicle

Event Action

Buzzer, Push message to APP, Full screen, Email, FTP, PTZ, Alarm output, Recording

Network Protocol

HTTP, HTTPS, TCP/IP, IPv4, IPv6, UPnP, UDP, RTSP, SMTP, NTP, DNS, DHCP, FTP, P2P, IP Address Filtering, DDNS, IEEE 802.1X, SNMP, 3G/4G, PPPoE

Remote Users

Up to 8 users

P2P

P2P, Web NAT

Interoperability

ONVIF, SDK, CGI

Security

IP Address Filtering, User Access Log, IEEE 802.1X, TLS, Signed Firmware, Secure Boot

ANR

Supported

Disk Group

Supported

RAID

RAID 0, RAID 1, RAID 5, RAID 6, RAID 10

HDD Interface

16 SATA interfaces, up to 16 TB per disk

Network Interface

2 × RJ-45, 10/100/1000/2500 Mbps self-adaptive Ethernet ports

eSATA

2 eSATA Interfaces

HDMI

4

VGA

1

Audio In/Out

1/1

Alarm In/Out

24/8

USB Interface

Front panel: 2 × USB 2.0; Rear panel: 2 × USB 3.0

RS-485 Interface

1

RS-232 Interface

1

Reset Button

On-board reset button

Power Supply

100 to 240VAC

Power Consumption

Max. 70W (without HDD)

Operating Conditions

-10 °C to 50 °C (14 °F to 122 °F)

Storage Conditions

Less than 90% RH

Certifications

CE/FCC

Dimensions (W × D × H)

Without rack ears: 436.8 × 521.0 × 151.6 mm (17.20 × 20.51 × 5.97 in)

With rack ears: 481.8 × 545.2 × 151.6 mm (18.97 × 21.47 × 5.97 in)

Net Weight

Approx. 10.6 kg (23.3 lb) without HDD
