Vanadium Oxide Uncooled Focal Plane Arrays

1/2.8" SRAVIS CMOS

Max Resolution

Sensor is 384×288, Image can be scaled up to 1280×1024

2592 (H)×1944 (V), 5MP

Pixel Pitch

17 μm

N/A

Spectral Range

8 to 14 μm

N/A

NETD

≤ 20mK

N/A

Shutter Speed

N/A

1/5 to 1/100,000s

Min Illumination

N/A

Color: 0.005 Lux @(F1.6, AGC ON),
B/W: 0.0001 Lux (F1.6, AGC ON),
0 Lux with illuminator on

Day & Night

N/A

Auto (ICR)

Fixed lens

Motorized zoom lens

Focal Length

9 mm, 15 mm, 25 mm optional

5.3 to 159 mm, 30x optical zoom

Max. Aperture

F1.0

F1.6 to F4.4

Field of View (FOV)

9 mm, H: 37°, V: 28°;
15 mm, H: 28°, V: 21°;
25 mm, H: 14°, V: 11°

H: 56.8° to 2.6°, V: 42.7° to 2.0°

Focus Control

Focus-free

Auto / Manual

Type

Warm light

Distance

Up to 30 m (98.4 ft)

Control

Auto / Manual

Supports human / vehicle detection.

Supports face, human, and vehicle detection & capture.
Supports human and vehicle attribute detection

Attribute Extraction

N/A

- Human Attributes: Gender, age, glasses, hat, bag, upper clothing color & style, lower clothing color & style, reflective vest.
- Vehicle Attributes: Type, color, brand, orientation.

Intelligent Analysis

Intrusion detection, smart motion detection, single line crossing, double line crossing, loitering, wrong-way detection, enter/leave area detection.
- Supports accurate target classification (human/vehicle)

Intrusion detection, smart motion detection, single line crossing, double line crossing, loitering, wrong-way detection, area people limit, perimeter detection, illegal parking, running detection, fall detection, fight detection.
- Supports accurate target classification (human/vehicle)

Smoke and Flame Detection

N/A

Supported

People Counting

Supported

Supported

Smoking Detection

Supported

N/A

Fire Spot Detection

Supported

N/A

Stream1: 1280×1024, 1280×720, 384×288,
Stream2: D1, CIF

Stream1: 2592×1944, 2592×1520, 1920×1080, 1280×720
Stream2: D1, VGA, CIF
Stream3: VGA, CIF, QVGA

Frame Rate

Up to 25fps

Up to 25/30fps

Bit Rate Control

CBR/VBR

CBR/VBR

Bit Rate

Main stream: 100 Kbps to 8 Mbps,
Sub stream: 10 Kbps to 6 Mbps

Stream1: 200 kbps to 12 Mbps,
Stream2: 100 kbps to 6 Mbps
Stream3: 100 kbps to 3 Mbps

Smart Encoding

Supported

Supported

Region of Interest (ROI)

N/A

Supported

Audio Compression

N/A

G.711 A-law, G.711 μ-law, RAW_PCM

Audio Bit Rate

N/A

64 Kbps (G.711), 128 Kbps (RAW_PCM)

Brightness, Contrast, Sharpness

Brightness, Saturation, Contrast, Sharpness

Scene Mode

Mirror

Indoor, Outdoor, Mirror

Pseudo-color Setting

Up to 17 colors (White-hot / Black-hot / Rainbow / Iron red / HSV /Bone / Cool / Copper / Fire-hot / Pink / Spring / Summer / Autumn / Winter / Jet / Flame / Rose -Bengal)

N/A

FFC Control

Auto / Manual

N/A

Exposure Mode

N/A

Auto / Manual

White Balance

N/A

Auto / Tungsten / Fluorescent / Daylight / Shadow

Day/Night Setting

N/A

Auto / Day / Night / Timer

Noise Reduction

2D/3D DNR

2D/3D DNR

Image Enhancement

N/A

WDR, HLC, BLC, Defog, Anti-shake

Wide Dynamic Range

N/A

True WDR(120dB)

Privacy Masking

Supported

Supported

Temperature Range

-20°C to 150°C (-4°F to 302°F)

Accuracy

±2°C / ±2%

Temperature Detection

3 temperature measurement rule types, 20 rules in total, 1 full screen, 19 others (spot, areas, line).

Temperature Alarm

Supports threshold alarm, temperature difference alarm, range alarm, and temperature rise alarm.

Temperature Display

Display in the lower left corner; follow the cursor display of the highest temperature, lowest temperature or average temperature

Response Time

≤ 30ms

Pan/Tilt Range

Pan: 0° to 360° endless, Tilt: -90° to +90°

Pan Speed

Pan: 0.01° to 20°/s, preset speed: 20°/s

Tilt Speed

Tilt: 0.01° to 10°/s, preset speed: 10°/s

Preset Accuracy

± 0.1°

Preset

400

Track

6 tracks

Scan

8 scans

Tour

12 tours, up to 32 presets per patrol

Power-Off Memory

Supported

3D Positioning

Supported

Idle Motion

The time can be set (1-240 minutes), and functions such as preset positions, patrols, scans, and tracks can be run.

Alarm Triggers

IVS, Temperature anomaly, Motion detection, Alarm Input, Disk alarm, Network alarm

Event Actions

Alarm output, Alarm record, SMTP, FTP upload, Audible alarm output

Protocols

IPv4/IPv6, HTTP/HTTPS, DNS, DDNS, DHCP, PPPOE, RTSP/RTP/RTCP, TCP/UDP, NTP, ARP, UPnP, FTP, SMTP, QoS, 802.1x, SNMP, Multicast

Application Programming Interface

ONVIF (Profile S/T/G/M), CGI, SDK

Max Concurrent Streams

10 channels

User/Host Level

32+ users, 3 levels: Administrator, Operator, Media user

Web Viewer

<IE11, Chrome, Firefox, Microsoft Edge

OS / Firmware Protect

Encrypted firmware, Secure boot, Signed firmware

User Authentication

Digest authentication, Prevent brute-force attack

Network Authentication

IEEE 802.1X (EAP-TLS)

Secure Communication

HTTPS, WSS (WebSocket Secure), SRTP

Access Control

IP-based access control, Auto logout

Data Protect

Encryption credentials

Audit

Access / System / Event Log management

Supply Chain Security

SBOM

Network Interface

RJ-45 Ethernet (10/100BASE-T)

Built-in Speaker

Supported (visible)

Alarm Interface

1 input, 1 output (thermal)

Control Interface

RS-485

CVBS Output

BNC (visible)

SD Card Slot

MicroSD card slot (max. 1 TB)
*Memory card must be factory pre-installed and is not field-installable.

Language

English, Chinese, Traditional Chinese, Polish, Italian, Portuguese, Spanish, Russian, French, Czech, Hungarian, Japanese, Korean. Default: English

Power Supply

12 VDC

Power Consumption

Typical: 18 W, Max 36 W

Operating Temperature

-40°C to 60°C (-40°F to 140°F)

Operating Humidity

≤ 95% RH (non-condensing)

Ingress Protection

IP66

Wiper

Supported

Certifications

CE-EMC
- EN 55032, EN IEC 61000-6-4, EN IEC 61000-3-2, EN 61000-3-3, EN 55035, EN 50130-4
FCC 47 CFR Part 15 Subpart B

Material

Metal

Dimensions

348 × 200 × 200 mm (13.7 × 7.87 × 7.87 inch)

Net Weight

Approx. 5 kg (11.0 lb)

Detect

103 to 3,090 m (337.93 to 10,137.8 ft)

Observe

41.2 to 1,236 m (135.17 to 4,055.1 ft)

Recognize

20.6 to 618 m (67.59 to 2,027.6 ft)

Identify

10.3 to 309 m (33.79 to 1,013.8 ft)

Thermal Lens

9 mm

15 mm

25 mm

Detection (Human: 1.8×0.5 m)

265 m
(869.4 ft)

441 m
(1,446.9 ft)

735 m
(2,411.4 ft)

Detection (Vehicle: 4×1.5 m)

812 m
(2,664.0 ft)

1,353 m
(4,439.0 ft)

2,255 m
(7,398.3 ft)

Recognition (Human: 1.8×0.5 m)

66 m
(216.5 ft)

110 m
(360.9 ft)

184 m
(603.7 ft)

Recognition (Vehicle: 4×1.5 m)

203 m
(666.0 ft)

338 m
(1,108.9 ft)

564 m
(1,850.4 ft)

Identification (Human: 1.8×0.5 m)

33 m
(108.3 ft)

55 m
(180.5 ft)

92 m
(301.8 ft)

Identification (Vehicle: 4×1.5 m)

101 m
(331.4 ft)

169 m
(554.5 ft)

282 m
(925.2 ft)

Note:
Distances are calculated based on Johnson's Criteria.
Detection: Object must be covered by ≥1.5 pixels.
Recognition: Object must be covered by ≥6 pixels.
Identification: Object must be covered by ≥12 pixels.

Lens

9 mm

15 mm

25 mm

Temperature Measurement (1 ×1 m)

106 m
(347.8 ft)

176 m
(577.4 ft)

294 m
(964.6 ft)

Temperature Measurement (0.2×0.2 m)

21 m
(68.9 ft)

35 m
(114.8 ft)

59 m
(193.6 ft)

Fire Detection (1×1 m)

265 m
(869.4 ft)

441 m
(1,446.9 ft)

735 m
(2,411.2 ft)

Fire Detection (0.2×0.2 m)

53 m
(173.9 ft)

88 m
(288.7 ft)

147 m
(482.3 ft)

Values are for reference only. Actual detection range may vary with atmospheric conditions, target size, and installation environment.
