Image Sensor

1/1.8” Progressive Scan CMOS

Max Resolution

8MP, 3840(H) × 2160(V)

Shutter Speed

1/5 to 1/20,000s

Min Illumination

Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0.001 Lux @ (F1.6, AGC ON), 0 Lux with illuminator on

Day & Night

Auto (ICR)

Angle Adjustment

Pan: 0˚ to 360˚, Tilt: 0˚ to 90˚, Rotation: 0˚ to 360˚

Lens Type

Fixed lens, Fixed focal

Focal Length

2.8 mm, 4 mm optional

Max. Aperture

F1.6

Field of View (FOV)

2.8 mm:

 - H: 110.5° , V: 56.5°

4 mm:

 - H: 88.4° , V: 50°

Iris

Fixed Iris

Type

IR, Warm light (Smart Dual-light)

IR wavelength

850 nm

Distance

IR distance up to 40 m (131.2 ft)

Warm light distance up to 30 m (98.4 ft)

Control

IR mode, White mode, Intelligent mode, None

AI Multi-Target

- Supports face, human, and vehicle detection & capture

- Supports human and vehicle attribute detection

- Supports multiple frame modes: Full Frame, Four-Corner Frame, Mosaic

Attribute Extraction

Human Attributes: Gender, age, glasses, hat, bag, upper clothing color & style, lower clothing color & style, reflective vest.

Vehicle Attributes: Type, color, brand, orientation

Intelligent Analysis

Intrusion detection, smart motion detection, single line crossing, double line crossing, loitering, wrong-way detection, area people limit, perimeter detection, illegal parking, running detection, fall detection, fight detection.

- Supports accurate target classification (human/vehicle)

People Counting

Supported

Number of Streams

3 Streams

Resolution

Stream1: 3840×2160, 2592×1944, 2592×1520, 2560×1440, 2304×1296, 1920×1080, 1280×720

Stream2: D1, VGA, CIF

Stream3: VGA, CIF, QVGA

Frame Rate

Up to 25/30fps

Bit Rate Control

CBR/VBR

Bit Rate

Stream1: 200 Kbps to 16 Mbps

Stream2: 100 Kbps to 6 Mbps

Stream3: 100 Kbps to 3 Mbps

Smart Encoding

Supported

Region of Interest (ROI)

Off/On (8 Zone, Rectangle)

Audio Compression

G.711 A-law, G.711 μ-law, RAW_PCM

Audio Bit Rate

64 Kbps (G.711), 128 Kbps (RAW_PCM)

Image Adjustment

Brightness, Sharpness, Contrast, Saturation adjustable

Scene Mode

Indoor, Outdoor, Mirror, Corridor mode

Exposure Mode

Auto, Manual, Shutter priority

White Balance

Auto, Tungsten, Fluorescent, Daylight, Shadow, Manual

Day/Night Setting

Auto, Day, Night, Timer

Noise Reduction

2D/3D DNR

Image Enhancement

HLC, BLC, Defog, WDR

Wide Dynamic Range

True WDR (120dB)

Privacy Masking

4 areas

Alarm Triggers

IVS, Motion detection, Alarm input, Network alarm, Disk alarm, Day/Night switch alarm, Abnormal sound detection

Event Actions

Alarm record, Alarm output, FTP upload, SMTP upload, Snapshot, Audible alarm output, White light alarm output

Protocols

IPv4/IPv6, HTTP/HTTPS, DNS, DDNS, DHCP, PPPoE, RTSP/ RTCP/RTP, TCP/UDP, NTP, ARP, UPnP, FTP, SMTP, QoS, ICMP, IGMP, SMTP, 802.1x, SNMP, Multicast

Application Programming Interface

ONVIF (Profile S/T/G/M), SDK, CGI

Max Concurrent Streams

10 channels

User/Host Level

32+ users, 3 levels: Administrator, Operator, Media user

Web Viewer

<IE11, Chrome, Firefox, Microsoft Edge

OS / Firmware Protect

Encrypted firmware, Secure boot, Signed firmware

User Authentication

Digest authentication, Prevent brute-force attack

Network Authentication

IEEE 802.1X (EAP-TLS)

Secure Communication

HTTPS, WSS (WebSocket Secure), SRTP

Access Control

IP-based access control, Auto logout

Data Protect

Encryption credentials

Audit

Access / System / Event Log management

Secure Storage

SDcard partition encrypt (AES-256), Secure element

Supply Chain Security

SBOM

Network Interface

1 × Ethernet (10/100 Base-T), RJ-45 connector

Built-in Microphone

Supported

Built-in Speaker

Supported

Audio Interface

1ch Input, 1ch Output

Alarm Interface

1ch Input, 1ch Output

SD Card Slot

Built-in microSD card slot, up to 1 TB

Reset Button

Supported

Language

English, Chinese, Traditional Chinese, Polish, Italian, Portuguese, Spanish, Russian, French, Czech, Hungarian, Japanese, Korean. Default: English

Power Supply

12 VDC (-10% to +25%) / PoE (802.3af)

Power Consumption

Typical: 3.5 W (12 VDC);

Max (IR on + Focusing + Speaker): 10.8 W (12 VDC)

Operating Temperature

-40°C to 60°C (-40°F to 140°F )

Operating Humidity

Less than 95% RH

Ingress Protection

IP66

Certifications

CE-EMC

 - EN 55032, EN IEC 61000-6-4, EN IEC 61000-3-2, EN 61000-3-3, EN 55035, EN 50130-4

FCC 47 CFR Part 15 Subpart B

Material

Aluminum alloy + plastic

Dimensions

242.6 × 87.7 × 97.2 mm (9.55 × 3.45 × 3.83 inch)

Net Weight

Approx. 0.9 kg (1.98 lb)

Detect

2.8 m: 89.7 m (294.3 ft); 4 mm: 100 m (328.1 ft)

Observe

2.8 m: 35.9 m (117.8 ft); 4 mm: 40 m (131.2 ft)

Recognize

2.8 m: 17.9 m (58.7 ft); 4 mm: 20 m (65.6 ft)

Identify

2.8 m: 9 m (29.5 ft); 4 mm: 10 m (32.8 ft)
