1/3" Progressive Scan CMOS
3.6mm fixed lens
Max 15fps@8MP
Video transmission 300m
Illumination distance up to 20m
2D DNR, DWDR, ICR, BLC, GLOBAL, MIRROR
Support TVI/ AHD/CVI/CVBS Output
Built-in Mic, Transmits both HD video and audio over the same coaxial cable
11 languages
IP66
Camera | |
Image Sensor | 1/3" Progressive Scan CMOS |
Signal System | PAL/NTSC |
Electronic Shutter | Auto |
Min. illumination | Color: 0.05Lux@(F1.2, AGC ON) ; B/W: 0Lux with illumination on |
S/N Ratio | More than 48dB |
Illumination Distance | up to 20m |
Illumination On/Off Control | Auto/Manual |
LEDs | 2pcs white lights |
OSD Joystick | Support |
Up the Coax | Support |
Pan/Tilt/Rotation Range | Pan:0˚~360˚; Tilt:0˚~90˚; Rotation:0˚~360˚ |
Audio | Built-in Microphone (TVI) |
Language | ENGLISH, 中文, ESPANOL, FRANCAIS, 繁体中文, PYCCKNN, ITALIANO, JAPANESE, KOREAN, POLSKI, PROTUGUES |
Lens | |
Lens Type | Fixed |
Iris | Fixed Iris |
Focal Length | 3.6mm |
F Number | F1.0 |
Angle of View | H: 76.8°, V: 41.5° |
Video | |
Resolution | 8MP (3840×2160) |
Frame Rate | TVI/AHD/CVI: 8MP 15fps/12.5fps, AHD/TVI: 5MP 20fps/12.5fps, 4MP 25fps/30fps/15fps, 1080P 25fps/30fps CVI: 4MP 25fps/30fps CVBS: PAL/NTSC |
Video Output | Support TVI/AHD/CVI/CVBS output |
OSD Menu | Support |
Wide Dynamic Range | DWDR, OFF/ON |
Gain Control | Auto |
Noise Reduction | 2D DNR, AUTO/MANUAL (0-10) |
White Balance | Auto |
BLC | Support |
General | |
Power Supply | DC12V±10% |
Power Consumption | Max. 5W (12V DC, IR ON) |
Operating Temperature | -10 °C ~ 55 °C (14°F ~ 131 °F) |
Operating Humidity | Less than 85% RH |
Ingress Protection | IP66 |
Certifications | CE/FCC |
Casing | Metal |
Dimensions | 183.4×65.2×58.5mm (7.22”×2.57”×2.3”) |
Net Weight | 0.29 kg (0.64 lb) |
