SN-CH515F-R2

Outdoor Housing

Specification

Download

Accessories

Parameters
Application Model	SN-IPCXXXXHAN
Color	White
Fan	Support
Material	Front cover and rear cover: Aluminum Top cover and bottom cover: Aluminum Alloy Sunshield: PP+GF (glass-fiber-reinforced polypropylene)
Illumination Type	IR
Wavelength	850 nm
Illumination Distance	≥ 80 m
Illumination Setting (Automatic Control)	1 to 3 Lux on, 2 to 6 Lux off
IR Control	Photosensitive automatic control (default) / Camera control Two optional options
Power Supply	DC12V or PoE+ (802.3at) optional
Power	Max. 30W (IR + fan on)
Working Temperature	-20°C to 60°C (-4°F to 140°F)
Operating Humidity	0% to 90% RH
Ingress Protection	IP66
Window Size	110 × 90 mm (max. support for lenses with an outer diameter of less than 63mm)
Internal Installation Space (L × W × H)	275 × 110 × 90 mm (10.83 × 4.33 × 3.54 inch)
Product Dimensions (L × W × H)	471.1 × 172.3 × 125.2 mm (18.55 × 6.78 × 4.93 inch)
Product Weight	2.4 kg (5.29 lb)
Mounting	2 screws
Equipped with rubber sealing gasket	Yes
Front window thickness	>=3mm

Read remainder 0%

Download

SN-CH515F-R2_Datasheet_202512_beta.pdf Download

Accessories

SN-BK385

SN-BK385

Wall Mount Bracket with Housing
