Image Sensor

Vanadium Oxide Uncooled Focal Plane Arrays

1/2.8" CMOS

Max Resolution

Sensor is 400×300. Image can be scaled up to 704×576

1920(H) × 1080(V)

Pixel Pitch

17 µm

N/A

Spectral Range

8 to 14 µm

N/A

NETD

≤ 40mK

N/A

Shutter Speed

N/A

1/5 to 1/20,000s

Min Illumination

N/A

Color: 0.1Lux @(F2.0, AGC ON),
B/W: 0.01Lux @(F2.0, AGC ON), 0Lux with IR on

Day & Night

N/A

Auto (ICR)

Lens Type

Fixed lens

Varifocal lens

Focal Length

8 mm, 15 mm, 25 mm, 35 mm, 50 mm optional

5 to 50 mm

Max. Aperture

F1.0

F2.0

Field of View (FOV)

8 mm, H: 46°, V: 35.3°
15 mm, H: 25.5°, V: 19.2°
25 mm, H: 15.4°, V: 11.6°
35 mm, H: 11°, V: 9°
50 mm, H: 7.7°, V: 5.8°

H: 50.85° to 7.67°, V: 27.78° to 4.36°

Focus Control

Manual focus

Motorized focus

Supports human/vehicle detection.

Human and vehicle detection

Intelligent Analysis

Intrusion, single line crossing, double line crossing, loitering, wrong-way detection, enter area, and leave area.
- Supports accurate target classification (human/vehicle)

Intrusion, single line crossing, double line crossing, loitering, wrong-way detection, enter area, and leave area.
- Supports accurate target classification (human/vehicle)

Smoke and Flame Detection

N/A

Supported

People Counting

Supported

Supported

Smoking Detection

N/A

Fire Spot Detection

Supported

N/A

704×576 @25/30fps

1920×1080, 1280×720

Sub Stream

CIF @25/30fps

D1, VGA, 640×360, CIF, QVGA

Frame Rate

Up to 25/30fps

Bit Rate Control

CBR/VBR

CBR/VBR

Bit Rate

Main stream: 100 Kbps to 6 Mbps,
Sub stream: 10 Kbps to 1.5 Mbps

Main Stream: 100 Kbps to 12 Mbps
Sub Stream: 10 Kbps to 6 Mbps

Smart Encoding

Supported

Supported

Audio Compression

G.711 A-law, G.711 μ-law, RAW_PCM

G.711 A-law, G.711 μ-law, RAW_PCM

Audio Bit Rate

64 Kbps (G.711), 128 Kbps (RAW_PCM)

64 Kbps (G.711), 128 Kbps (RAW_PCM)

Image Adjustment

Brightness, Contrast, Sharpness

Brightness, Saturation, Contrast, Sharpness

Scene Mode

Mirror

Indoor, Outdoor, Mirror

Pseudo-color Setting

Up to 17 colors (White-hot / Black-hot /

 Rainbow / Iron red / HSV /Bone / Cool /

Copper / Fire-hot / Pink / Spring / Summer

/ Autumn / Winter / Jet / Flame / Rose -Bengal)

N/A

FFC Control

Auto / Manual

N/A

Exposure Mode

N/A

Auto / Manual

White Balance

N/A

Auto / Tungsten / Fluorescent / Daylight / Shadow / Manual

Day/Night Setting

N/A

Auto / Day / Night / Timer

Noise Reduction

2D/3D DNR

Auto, Day, Night, Timer

Image Enhancement

N/A

HLC, BLC, Defog, WDR

Wide Dynamic Range

N/A

True WDR 120dB

OSD

Up to 8 OSD

Up to 8 OSD

Privacy Masking

Up to 4 areas

Up to 4 areas

Temperature Range

-20°C to 150°C (-4°F to 302°F)

Accuracy

±2°C / ±2%

Temperature Detection

3 temperature measurement rule types, 20 rules in total, 1 full screen, 19 others (spot, areas, line).

Temperature Alarm

Temperature difference  alarm, Threshold alarm, Temperature rise  alarm

Temperature Display

Display in the lower left corner; follow the cursor display of the highest temperature, lowest temperature or average temperature

Response Time

≤ 30ms

Image Fusion

Fusion view of thermal view and overlaid details of the optical channel

Alarm Triggers

IVS, Motion detection, Alarm input, Network alarm, Disk alarm, Abnormal sound detection

Event Actions

Alarm record, Alarm output, FTP upload, SMTP upload, Audible alarm output

Protocols

IPv4/IPv6, HTTP/HTTPS, DNS, DDNS, DHCP, PPPoE, RTSP/ RTCP/RTP, TCP/UDP, NTP, ARP, UPnP, FTP, SMTP, QoS, ICMP, IGMP, SMTP, 802.1x, SNMP, Multicast

Application Programming Interface

ONVIF (Profile S/T/G/M), SDK, CGI

Max Concurrent Streams

10 channels

User/Host Level

32+ users, 3 levels: Administrator, Operator, Media user

Web Viewer

<IE11, Chrome, Firefox, Microsoft Edge

OS / Firmware Protect

Encrypted firmware, Signed firmware

User Authentication

Digest authentication, Prevent brute-force attack

Network Authentication

IEEE 802.1X (EAP-TLS)

Secure Communication

HTTPS, WSS (WebSocket Secure), SRTP

Access Control

IP-based access control, Auto logout

Data Protect

Encryption credentials

Audit

Access / System / Event Log management

Secure Storage

SDcard partition encrypt(AES-256), Secure element

Supply Chain Security

SBOM

Network Interface

1 × Ethernet (10/100 Base-T), RJ-45 connector

Audio Interface

1ch Audio In, 1ch Audio Out

Alarm Interface

2ch Alarm In, 2ch Alarm Out

RS-485

1ch

Reset Button

Supported

Language

English, Chinese, Traditional Chinese, Polish, Italian, Portuguese, Spanish, Russian, French, Czech, Hungarian, Japanese, Korean. Default: English

Power Supply

12 VDC / PoE+ (802.3at)

Power Consumption

Without heating: Max 10W, Including heating: Max 24W

Operating Temperature

-40°C to 60°C (-40°F to 140°F)

Operating Humidity

0 to 90% RH (non-condensing)

Ingress Protection

IP66

Certifications

CE-EMC
- EN 55032, EN IEC 61000-6-3, EN IEC 61000-3-2, EN 61000-3-3, EN 55035, EN 50130-4
FCC 47 CFR Part 15 Subpart B

Material

Metal

Dimensions

(244.8 to 274.8) × 180.5 × 126.8 mm (9.64 to 10.82 × 7.11 × 4.99 inch)

Net Weight

2.5 Kg (5.51 lb)

Detect

88 to 530 m (288.7 to 1,738.8 ft)

Observe

35.2 to 212 m (115.5 to 695.5 ft)

Recognize

17.6 to 106 m (57.7 to 347.8 ft)

Identify

8.8 to 53 m (28.9 to 173.9 ft)

Thermal Lens

8 mm

15 mm

25 mm

35 mm

50 mm

Detection

(Human: 1.8×0.5 m)

235 m
(771.0 ft)

441 m
(1,446.9 ft)

735 m
(2,411.4 ft)

1,029 m
(3,376.0 ft)

1,471 m
(4,826.1 ft)

Detection

(Vehicle: 4×1.5 m)

722 m
(2,368.8 ft)

1,353 m
(4,439.0 ft)

2,255 m
(7,398.3 ft)

3,157 m
(10,357.6 ft)

4,510 m
(14,796.6 ft)

Recognition

(Human: 1.8×0.5 m)

59 m
(193.6 ft)

110 m
(360.9 ft)

184 m
(603.7 ft)

257 m
(843.2 ft)

368 m
(1,207.4 ft)

Recognition

(Vehicle: 4×1.5 m)

180 m
(590.6 ft)

338 m
(1,108.9 ft)

564 m
(1,850.4 ft)

789 m
(2,588.6 ft)

1,127 m
(3,697.5 ft)

Identification

(Human: 1.8×0.5 m)

29 m
(95.1 ft)

55 m
(180.5 ft)

92 m
(301.8 ft)

129 m
(423.2 ft)

184 m
(603.7 ft)

Identification

(Vehicle: 4×1.5 m)

90 m
(295.3 ft)

169 m
(554.5 ft)

282 m
(925.2 ft)

395 m
(1,295.9 ft)

564 m
(1,850.4 ft)

Note:
Distances are calculated based on Johnson's Criteria.
Detection: Object must be covered by ≥1.5 pixels.
Recognition: Object must be covered by ≥6 pixels.
Identification: Object must be covered by ≥12 pixels.

Lens

8 mm

15 mm

25 mm

35 mm

50 mm

VCA Detection

(Human: 1.8×0.5 m)

50 m
(164.0 ft)

92 m
(301.8 ft)

105 m
(344.5 ft)

210 m
(689.0 ft)

284 m
(931.8 ft)

VCA Detection

(Front/Rear of Vehicle: 4×1.5 m)

100 m
(328.1 ft)

120 m
(393.7 ft)

200 m
(656.2 ft)

350 m
(1,148.3 ft)

450 m
(1,476.4 ft)

Temperature Measurement

(1 ×1 m)

94 m
(308.4 ft)

176 m
(577.4 ft)

294 m
(964.6 ft)

412 m
(1,351.7 ft)

588 m
(1,929.1 ft)

Temperature Measurement

(0.2×0.2 m)

19 m
(62.3 ft)

35 m
(114.8 ft)

59 m
(193.6 ft)

82 m
(269.0 ft)

118 m
(387.1 ft)

Fire Detection

(1×1 m)

235 m
(771.0 ft)

441 m
(1,446.9 ft)

735 m
(2,411.2 ft)

1,029 m
(3,376.0 ft)

1,471 m
(4,826.1 ft)

Fire Detection

(0.2×0.2 m)

47 m
(154.2 ft)

88 m
(288.7 ft)

147 m
(482.3 ft)

206 m
(675.9 ft)

294 m
(964.6 ft)

Note:
Values are for reference only. Actual detection range may vary with atmospheric conditions, target size, and installation environment.
