Image Sensor

Vanadium Oxide Uncooled Focal Plane Arrays

Max Resolution

Sensor is 640×512. Image can be scaled up to 1280×1024

Pixel Pitch

12 µm

Spectral Range

8 to 14 µm

NETD

≤ 40mK

Lens Type

Fixed lens

Focal Length

25 mm, 50 mm, 75 mm, 100 mm optional

Max. Aperture

F1.0

Field of View (FOV)

25 mm, H: 17°, V: 14°
50 mm, H: 8°, V: 7°
75 mm, H: 6°, V: 5°
100 mm, H: 4.3°, V: 3.5°

Focus Control

Motorized focus

AI Multi-Target

Supports human/vehicle detection (ship detection optional).

Intelligent Analysis

Intrusion, single line crossing, double line crossing, loitering, wrong-way detection, enter area, and leave area.
- Supports accurate target classification (human/vehicle)

People Counting

Supported

Smoking Detection

Supported

Fire Spot Detection

Supported

Resolution

Stream1: 1280×1024, 1280×720, 640×512
Stream2: D1, CIF

Frame Rate

Up to 25fps

Bit Rate Control

CBR/VBR

Bit Rate

Main stream: 100 Kbps to 8 Mbps,
Sub stream: 100 Kbps to 6 Mbps

Smart Encoding

Supported

Region of Interest (ROI)

Off/On (8 Zone, Rectangle)

Audio Compression

G.711 A-law, G.711 μ-law, RAW_PCM

Audio Bit Rate

64 Kbps (G.711), 128 Kbps (RAW_PCM)

Image Adjustment

Brightness, Contrast, Sharpness

Scene Mode

Mirror

Pseudo-color Setting

Up to 17 colors (White-hot / Black-hot / Rainbow / Iron red / HSV /Bone / Cool / Copper / Fire-hot / Pink / Spring / Summer / Autumn / Winter / Jet / Flame / Rose -Bengal)

FFC Control

Auto / Manual

Noise Reduction

2D/3D DNR

OSD

Up to 8 OSD

Privacy Masking

Up to 4 areas

Temperature Range

-20°C to 150°C (-4°F to 302°F)

Accuracy

±2°C / ±2%

Temperature Detection

3 temperature measurement rule types, 20 rules in total, 1 full screen, 19 others (spot, areas, line).

Temperature Alarm

Temperature difference  alarm, Threshold alarm, Temperature rise  alarm

Temperature Display

Display in the lower left corner; follow the cursor display of the highest temperature, lowest temperature or average temperature

Response Time

≤ 30ms

Alarm Triggers

IVS, Motion detection, Alarm input, Network alarm, Disk alarm, Abnormal sound detection

Event Actions

Alarm record, Alarm output, FTP upload, SMTP upload, Audible alarm output

Protocols

IPv4/IPv6, HTTP/HTTPS, DNS, DDNS, DHCP, PPPoE, RTSP/ RTCP/RTP, TCP/UDP, NTP, ARP, UPnP, FTP, SMTP, QoS, ICMP, IGMP, SMTP, 802.1x, SNMP, Multicast

Application Programming Interface

ONVIF (Profile S/T/G/M), SDK, CGI

Max Concurrent Streams

10 channels

User/Host Level

32+ users, 3 levels: Administrator, Operator, Media user

Web Viewer

<IE11, Chrome, Firefox, Microsoft Edge

OS / Firmware Protect

Encrypted firmware, Signed firmware

User Authentication

Digest authentication, Prevent brute-force attack

Network Authentication

IEEE 802.1X (EAP-TLS)

Secure Communication

HTTPS, WSS (WebSocket Secure), SRTP

Access Control

IP-based access control, Auto logout

Data Protect

Encryption credentials

Audit

Access / System / Event Log management

Secure Storage

SDcard partition encrypt(AES-256), Secure element

Supply Chain Security

SBOM

Network Interface

1 × Ethernet (10/100 Base-T), RJ-45 connector

Audio Interface

1ch input, 1ch output

Alarm Interface

1ch input, 1ch output

Control Interface

1ch RS-485, 1ch RS-232

SD Card Slot

Built-in, up to 512 GB

Reset Button

Supported

Language

English, Chinese, Traditional Chinese, Polish, Italian, Portuguese, Spanish, Russian, French, Czech, Hungarian, Japanese, Korean. Default: English

Power Supply

12 VDC ±25%

Power Consumption

Max 4.5W

Operating Temperature

-40°C to 60°C (-40°F to 140°F)

Operating Humidity

≤90% RH (non-condensing)

Ingress Protection

N/A

Certifications

CE-EMC
- EN 55032, EN IEC 61000-6-3, EN IEC 61000-3-2, EN 61000-3-3, EN 55035, EN 50130-4
FCC 47 CFR Part 15 Subpart B

Material

Metal

Dimensions

64.8× 52 × 52 mm (2.55× 2.05 × 2.05 inch) without lens

Net Weight

0.2 kg (0.44 lb) without lens

Thermal Lens

25 mm

50 mm

75 mm

100 mm

Detection

(Human: 1.8×0.5 m)

1,042 m
(3,418.6 ft)

2,083 m
(6,834.0 ft)

3,125 m
(10,252.6 ft)

4,167 m
(13,671.3 ft)

Detection

(Vehicle: 4×1.5 m)

3,194 m
(10,479 ft)

6,389 m
(20,961.3 ft)

9,583 m
(31,440.3 ft)

12,778 m
(41,922.6 ft)

Recognition

(Human: 1.8×0.5 m)

260 m
(853 ft)

521 m
(1,709.3 ft)

781 m
(2,562.3 ft)

1,042 m
(3,418.6 ft)

Recognition

(Vehicle: 4×1.5 m)

799 m
(2,621.4 ft)

1,597 m
(5,239.5 ft)

2,396 m
(7,860.9 ft)

3,194 m
(10,479.0 ft)

Identification

(Human: 1.8×0.5 m)

130 m
(426.5 ft)

260 m
(853 ft)

391 m
(1,282.8 ft)

521 m
(1,709.3 ft)

Identification

(Vehicle: 4×1.5 m)

399 m
(1,309.1 ft)

799 m
(2,621.4 ft)

1,198 m
(3,930.5 ft)

1,597 m
(5,539.5 ft)

Note:
Distances are calculated based on Johnson's Criteria.
Detection: Object must be covered by ≥1.5 pixels.
Recognition: Object must be covered by ≥6 pixels.
Identification: Object must be covered by ≥12 pixels.

Lens

25 mm

50 mm

75 mm

100 mm

VCA Detection

(Human: 1.8×0.5 m)

101 m
(331.4 ft)

235 m
(771 ft)

336 m
(1,102.4 ft)

470 m
(1,542.0 ft)

VCA Detection

(Front/Rear of Vehicle: 4×1.5 m)

230 m
(754.6 ft)

400 m
(1,312.3 ft)

630 m
(2,066.9 ft)

800 m
(2,624.7 ft)

Temperature Measurement

(1 ×1 m)

417 m
(1,368.1 ft)

833 m
(2,732.9 ft)

1,250 m
(4,101.1 ft)

1,667 m
(5,469.2 ft)

Temperature Measurement (0.2×0.2 m)

83 m
(272.3 ft)

167 m
(547.9 ft)

250 m
(820.2 ft)

333 m
(1,092.5 ft)

Fire Detection

(1×1 m)

1,042 m
(3,418.6 ft)

2,083 m
(6,834.0 ft)

3,125 m
(10,252.6 ft)

4,167 m
(13,671.3 ft)

Fire Detection

(0.2×0.2 m)

208 m
(682.4 ft)

417 m
(1,368.1 ft)

625 m
(2,050.5 ft)

833 m
(2,732.9 ft)

Note:
Values are for reference only. Actual detection range may vary with atmospheric conditions, target size, and installation environment.
