Image Sensor

Vanadium Oxide Uncooled Focal Plane Arrays

Max Resolution

Sensor is 640×512. Image can be scaled up to 1280×1024

Pixel Pitch

12 µm

Spectral Range

8 to 14 µm

NETD

≤ 40mK

Lens Type

Motorized lens

Focal Length

26 to 105 mm, 30 to 150 mm optional

Max. Aperture

F1.6 / F0.85 to F1.2

Field of View (FOV)

26 to 105 mm,
- H: 16.8° to 4.2°, V: 13.4° to 3.4°
30 to 150 mm,
- H: 14.5° to 2.9°, V: 11.6° to 2.3°

Focus Control

Motorized focus

AI Multi-Target

Supports human/vehicle detection (ship detection optional).

Intelligent Analysis

Intrusion, single line crossing, double line crossing, loitering, wrong-way detection, enter area, and leave area.
- Supports accurate target classification (human/vehicle)

People Counting

Supported

Smoking Detection

Supported

Fire Spot Detection

Supported

Main Stream

1280×1024, 1280×720, 640×512 @25fps

Sub Stream

D1, CIF @25fps

Bit Rate Control

CBR/VBR

Bit Rate

Main stream: 100 Kbps to 8 Mbps,
Sub stream: 100 Kbps to 6 Mbps

Smart Encoding

Supported

Region of Interest (ROI)

Off/On (8 Zone, Rectangle)

Audio Compression

G.711 A-law, G.711 μ-law, RAW_PCM

Audio Bit Rate

64 Kbps (G.711), 128 Kbps (RAW_PCM)

Image Adjustment

Brightness, Contrast, Sharpness

Scene Mode

Mirror

Pseudo-color Setting

Up to 17 colors (White-hot / Black-hot / Rainbow / Iron red / HSV /Bone / Cool / Copper / Fire-hot / Pink / Spring / Summer / Autumn / Winter / Jet / Flame / Rose -Bengal)

FFC Control

Auto / Manual

Noise Reduction

2D/3D DNR

OSD

Up to 8 OSD

Privacy Masking

Up to 4 areas

Temperature Range

-20°C to 150°C (-4°F to 302°F)

Accuracy

±2°C / ±2%

Temperature Detection

3 temperature measurement rule types, 20 rules in total, 1 full screen, 19 others (spot, areas, line).

Temperature Alarm

Temperature difference  alarm, Threshold alarm, Temperature rise  alarm

Temperature Display

Display in the lower left corner; follow the cursor display of the highest temperature, lowest temperature or average temperature

Response Time

≤ 30ms

Alarm Triggers

IVS, Motion detection, Alarm input, Network alarm, Disk alarm, Abnormal sound detection

Event Actions

Alarm record, Alarm output, FTP upload, SMTP upload, Audible alarm output

Protocols

IPv4/IPv6, HTTP/HTTPS, DNS, DDNS, DHCP, PPPoE, RTSP/ RTCP/RTP, TCP/UDP, NTP, ARP, UPnP, FTP, SMTP, QoS, ICMP, IGMP, SMTP, 802.1x, SNMP, Multicast

Application Programming Interface

ONVIF (Profile S/T/G/M), SDK, CGI

Max Concurrent Streams

10 channels

User/Host Level

32+ users, 3 levels: Administrator, Operator, Media user

Web Viewer

<IE11, Chrome, Firefox, Microsoft Edge

OS / Firmware Protect

Encrypted firmware, Signed firmware

User Authentication

Digest authentication, Prevent brute-force attack

Network Authentication

IEEE 802.1X (EAP-TLS)

Secure Communication

HTTPS, WSS (WebSocket Secure), SRTP

Access Control

IP-based access control, Auto logout

Data Protect

Encryption credentials

Audit

Access / System / Event Log management

Secure Storage

SDcard partition encrypt(AES-256), Secure element

Supply Chain Security

SBOM

Network Interface

1 × Ethernet (10/100 Base-T), RJ-45 connector

Audio Interface

1ch Audio In, 1ch Audio Out

Alarm Interface

1ch Alarm In, 1ch Alarm Out

Control Interface

1ch RS-485, 1ch RS-232

SD Card Slot

Built-in, up to 512 GB

Reset Button

Supported

Language

English, Chinese, Traditional Chinese, Polish, Italian, Portuguese, Spanish, Russian, French, Czech, Hungarian, Japanese, Korean. Default: English

Power Supply

12 VDC ±25%

Power Consumption

Max 5.6W

Operating Temperature

-40°C to 60°C (-40°F to 140°F)

Operating Humidity

≤90% RH (non-condensing)

Ingress Protection

N/A

Certifications

CE-EMC
- EN 55032, EN IEC 61000-6-3, EN IEC 61000-3-2, EN 61000-3-3, EN 55035, EN 50130-4
FCC 47 CFR Part 15 Subpart B

Material

Metal

Dimensions

64.8× 52 × 52 mm (2.55× 2.05 × 2.05 inch) without lens

Net Weight

0.2 kg (0.44 lb) without lens

Thermal Lens

26 to 105 mm

30 to 150 m

Detection (Human: 1.8×0.5 m)

1,083 to 4,375 m (3553.2 to 14,353.7 ft)

1,250 to 6,250 m (4101.1 to 20,505.3 ft)

Detection (Vehicle: 4×1.5 m)

3,322 to 13,417 m (10,899 to 44,019 ft)

3,833 to. 19,167 m (12,575.5 to 62,883.9 ft)

Recognition (Human: 1.8×0.5 m)

271 to 1,094 m (889.1 to 3,589.2 ft)

312 to 1,563 m (1,023.6 to 5,128.0 ft)

Recognition (Vehicle: 4×1.5 m)

831 to 3,354 m (2,726.4 to 11,003.9 ft)

958 to 4,792 m (3,143 to 15,721.8 ft)

Identification (Human: 1.8×0.5 m)

135 to 547 m (442.9 to 1,794.6 ft)

156 to 781 m (511.8 to 2,562.3 ft)

Identification (Vehicle: 4×1.5 m)

415 to 1,677 m (1361.5 to 5502 ft)

479 to 2,396 m (1,571.5 to 7,860.9 ft)

Note:
Distances are calculated based on Johnson's Criteria.
Detection: Object must be covered by ≥1.5 pixels.
Recognition: Object must be covered by ≥6 pixels.
Identification: Object must be covered by ≥12 pixels.

Lens

26 to 105 mm

VCA Detection (Human: 1.8×0.5 m)

Up to  480 m (1,574.8 ft)

Up to  705 m (2,313.0 ft)

VCA Detection (Front/Rear of Vehicle: 4×1.5 m)

Up to  840 m (2,755.9 ft)

Up to  1,200 m (3,937.0 ft)

Temperature Measurement (1 ×1 m)

433 to 1,750 m (1,420.6 to 5,741.5 ft)

500 to 2,500 m (1,640.4 to 8,202.1 ft)

Temperature Measurement (0.2×0.2 m)

87 to 350 m (285.4 to 1,148.3 ft)

100 to 500 m (328.1 to 1,640.4 ft)

Fire Detection (1×1 m)

1,083 to 4,375 m (3,553.2 to 14,353.7 ft)

1,250 to 6,250 m (4,101 to 20,505.3 ft)

Fire Detection (0.2×0.2 m)

217 to 875 m (712 to 2,870.7 ft)

250 to 1,250 m (820.2 to 4,101.1 ft)

Note:
Values are for reference only. Actual detection range may vary with atmospheric conditions, target size, and installation environment.
